- Page 1 Sivoia QED Euro-style ™ Keypads for use with Lutron Sivoia QED Motorized Window Treatment System SQE-2 SQE-3E SQE-RL SQE-3D SQE-33...
-
Page 2: Keypad Configurations
Check with your local electrical inspector for the local code requirements and wiring practices allowed in your area. Use only a cloth with warm water and mild soap to clean faceplates (no chemical cleaners). Keypad Configurations SQE-3E SQE-2 SQE-RL Status Indicator Status Indicator Status Indicator... -
Page 3: Button Functionality
Button Functionality Wiring Notes Tap the Open, Close, or Preset button to move the window System Maximums: treatments to the selected position. While pressing the Raise or — Up to 96 devices total on one system. Lower button, the window treatments will raise or lower. One transformer per EDU. -
Page 4: Installation
Installation Sivoia QED Keypad Wiring Keypad circuits are classified as Class 2 circuits (U.S.A.) and PELV circuits (IEC). When installing and wiring to these Keypads, follow all applicable national and/or local wiring regulations. Male EDU Connector Warning: Always turn Off the circuit breaker or remove the main fuse from the power line before doing any work. -
Page 5: Addressing The System
Addressing the System 5. Remove the faceplate from the Keypad. To remove the faceplate, pull outward at each corner, one corner at a Note: For the SQE-RL, use the buttons instead of time. buttons. 1. Enter programming mode on the Keypad by pressing and holding the Open ( ) and Close ( ) buttons... -
Page 6: Setting Limits
Setting Limits 4. Adjust the currently selected EDU to the desired level, using the Raise ( ) and Lower ( ) buttons on the Note: Entering Limit Setup mode may cause the Keypad. window treatments to move approximately 200 mm (8 in) up or down. - Page 7 EDU Assignment 4. Tap any button on an EDU to toggle between assignment or unassignment with the Keypad. Note: Entering Assignment mode will cause the window treatments to move between their Open and Use the Open ( ) button to step through each EDU in the Close limits.
-
Page 8: Storing Presets
To the extent permitted by law, Lutron EA Ltd. UK +44-(0)20-7702-065709.00 - Lutron EA and Lutron Electronics Co. Inc. (“Lutron”) make no warranties or representations as 6 Sovereign Close 18.00 GMT to the units except as set forth herein.
