6. Operation of PV-Inverter
6.1. Initialization for Regulation Type Setting
The Inverter provides a "Initialization" function at the first
1.
time start-up as an process in which user is able to select
the intended regulation type before normal operation.
2.
The inverter will not able to operate normally before
regulation setting is completed even though it is connected
correctly at both DC input and AC output.
3.
The folliwing figure illustrates the process of
"Initialization", and the display sequence of regulation
available.
4.
For example, if user need to set regulation type to RD1663,
user have to power on the inverter to start the
"Initialization" and change the menu by button control
until RD1663 present, hold on to this regulation page and
23
