Technical manual
MDARM
Arming module on RS-485 serial line
for intrusion detection systems to be
used with an external reader
1 DESCRIPTION
MDARM allows arming and disarming an intrusion detection
system using the same user identification method used by
the access control system.
If the intrusion detection unit to which MDARM is connected
supports access-enabled users, it can also be used to tem-
porarily arm and disarm its gate.
MDARM and the access control system use different sets of
Wiegand readers.
A A A
D0 D1 +
B A 12 V
READER
MAX 1 A DC RELAY OUTPUT
G
ON
485
12 V IN
+ A B IN1 IN2
H I
A Reader serial line*
B Relay outputs
C Dip switch selectors
D Relay status LEDs
E USB port
* The product with code OCMIN0100100 is only compatible
with Wiegand readers equipped with an internal pull-up on
their communication lines, products with different codes
are also compatible with Wiegand readers without internal
ULTRABUS
®
advanced serial bus
Addressee for this information:
B
NO C NC
REL
C
1 A @ 30 V
DC
D
1 2 3 4 5 6 7
REL
12 V
DC
25.5 mA MAX
E
F
RX 485 TX
OUT
1 2 3 4
J
F Serial status LEDs
G Power ON LED
H ULTRABUS serial line
I Zones
J Open collector outputs
User |
pull-ups.
MDARM is compatible with intrusion detection systems that
use the ULTRABUS serial line.
2 TECHNICAL DATA
Model
General features
Operating voltage Power supply
Consumption at
power voltage
O.C. output maximum current
Working temperature
Relative humidity
Fixing centre distance
8
Dimensions
Weight
Parts supplied: technical manual.
5
3 INSTALLATION


General warnings are at the end of this manual.
MDARM is designed to be installed in a box (e.g. a junction
box) equipped with protection against opening carried out
by the installer.
3.1 Wirings


Wire devices while they are disconnected from power/
mains.
1 1 1
Installer
MDARM
Idle mode
Maximum
−10 ÷ +55
max 93%
120.0
W 129 × H 80 × D 20
12 V
8.0 mA
14 mA
30 mA
°C
mm
mm
103 g
