- Page 1 Horizen 24 Installation Guide Register product to operate at IMPORTANT IMPORTANT www.peakscientific.com/activate Horizen 24 Installation Guide Rev 3 RSID 5112 EN 05/02/24...
- Page 2 Register Product to Operate To begin operation of your unit you will need to register your generator. You can do so by visiting www.peakscientific.com/activate or by downloading the Peak Gas App. Registering will activate your 2 year warranty* - covering every single component in your generator.
-
Page 3: Change History
User Manual for your gas generator. Thank you for selecting Peak Scientific to meet your Gas Generation needs, and should you require any further assistance or support please do not hesitate to contact Peak Scientific or Peak Partner from which you purchased your Generator. -
Page 4: Safety Notices
If the user employs an operating procedure, item of equipment or a method of working which is not specifically recommended by Peak Scientific, the user must ensure that the equipment will not be damaged or become hazardous to persons or property. -
Page 5: Fittings Kit
Fittings Kit US Mains Cable 240V C19 6-15 04-1024 Flow Control Silencer 02-1096 1/4” Teflon Tubing 00-1266 UK Mains Cable C19 04-1025 1/4” Compression Fitting 02-4421 6mm PTFE Tubing 00-1302 EU Mains Cable C19 04-1026 6mm Push Fit Fitting 02-4600 US Mains Cable 120V C19 5-15 04-1035 6mm PE Tubing 00-1282 Page 5... - Page 6 WARNING 0° 0° Unpack the generator from the shipping crate, referring to the unpacking instruction located on the outside of the box, and position on a flat surface in desired area. The unit should be left to acclimatize for 3 hours. WARNING the weight of the unit constitutes a two man lift.
- Page 7 WARNING CAUTION 00-1282 00-1282 Connect the 6mm Polyethylene Tubing (00-1282) to the 6mm Push Fit Fitting (02-4600). Fit the other end of the tubing to a suitable drain connection or container. WARNING: The container used MUST be a plastic material and MUST NOT be glass for safety reasons.
- Page 8 CAUTION 110V 240V Plug the mains cable into the corresponding 100VAC 50/60Hz, 120VAC 60Hz OR 230VAC 50/60Hz OR 240V 60Hz single phase power supply. CAUTION ensure the correct cable has been selected for your electrical supply Consult the Electrical Requirements section if you are unsure of the requirements of your generator.
- Page 9 REGISTER YOU GENERATOR WITH OUR APP OR VISIT WWW.PEAKSCIENTIFIC.COM/ACTIVATE SERIAL: [ XXXXXXXXXXXX ] I’ve got my pin Remove the TWO transit bolts from the base of the generator, turning anti-clockwise using a 13mm spanner. Press OK on the HMI screen once the bolts have been removed. REGISTER YOU GENERATOR WITH OUR APP OR VISIT WWW.PEAKSCIENTIFIC.COM/ACTIVATE SERIAL: [ XXXXXXXXXXXX ]...
- Page 10 REGISTER YOU GENERATOR WITH OUR APP OR VISIT WWW.PEAKSCIENTIFIC.COM/ACTIVATE SERIAL: [ XXXXXXXXXXXX ] I’ve got my pin Enter your PIN. If entered incorrectly the screen will briefly display a wrong pass code warning before allowing a new PIN entry attempt. REGISTER YOU GENERATOR WITH OUR APP OR VISIT WWW.PEAKSCIENTIFIC.COM/ACTIVATE SERIAL: [ XXXXXXXXXXXX ]...
- Page 11 REGISTER YOU GENERATOR WITH OUR APP OR VISIT WWW.PEAKSCIENTIFIC.COM/ACTIVATE SERIAL: [ XXXXXXXXXXXX ] I’ve got my pin Press Turn On in the corner of the HMI screen. The outlet pressure reading on the display will gradually increase to the factory set pressure of 100 psi (6.9 bar). The outlet pressure can be configured to 116 psi (8.0) bar by pressing the pressure reading and typing 116 if required.
- Page 12 After 30 minutes of running, press TURN OFF in the corner of the HMI screen. Once the pressure gauge on the HMI screen reads 0, the generator can be powered off and the silencer fitting can be removed from the Nitrogen port. 02-4421 02-4421 02-4600...
- Page 13 00-1302 00-1302 00-1266 00-1266 Attach the appropriate sized Teflon tubing to the fitting attached to the nitrogen port and connect to the gas inlet of your instrument. Switch the generator ON using the switch on the rear panel Page 13...
- Page 14 REGISTER YOU GENERATOR WITH OUR APP OR VISIT WWW.PEAKSCIENTIFIC.COM/ACTIVATE SERIAL: [ XXXXXXXXXXXX ] I’ve got my pin START UP DISCLAIMER The generator will be ready to be connected to your LC-MS Instrument after a 30 minute purge run as LC-MS grade purity will be achieved within this period. This only applies to the initial start up of the generator.
- Page 15 CONGRATULATIONS Your Peak Scientific gas generator is now fully installed, operational and ready to supply gas on demand to your instrument. Page 15...
-
Page 16: General Notes
Electrical Requirements Generator Voltage Frequency Plug Type UK, EU, US 240V, Horizen 24 100-240V 50-60Hz US 120V Please familiarise yourself with the full User Manual available at www.peakscientific. com/downloads. This includes all other technical specifications, operating instructions, service requirements, contact details and troubleshooting. - Page 17 Page 17...
- Page 18 Page 18...
- Page 19 Page 19...
- Page 20 User Manual for your gas generator. Peak Scientific has highly trained, fully certified Field Service Engineers located in over 20 countries across every continent around the world. This allows us to provide an industry-leading rapid response service to our customers.
