Quick Installation Guide
®
O2605CM Corner Mount Camera
Main Features
• Built-in PoE (Power over Ethernet).
• Converts HD-TVI cameras (up to 5MP) and analog cameras to IP. H.265
and H.264 compression
• 12V DC power output for powering cameras (max 500mA)
• Remote viewing support via web browser, mobile app, and VMS.
• Built in analytics provides functions for People and Vehicle, Face
Detection, Face Recognition and Intrusion.*
Remote Access
Default User Name: admin
Default Password: 1234
Connections
1. Power the O5E1 via a PoE Port from a Recorder or PoE Switch.
You can also power the O5E1 (Blue Arrow) via the 12VDC input.
PoE
12VDC
Input
2. Connect the video output from the camera pigtail to the video input
(Red Arrow) on the O5E1. The camera can be powered via the 12VDC
outputs (500mA max)
BNC Video Input
12VDC Output
*With Speco Blue Advanced Analytics Recorders
specotech.com | 1.800.645.5516
RG-59 or RG-6
