Speco CVC-521BC Specifications

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
CVC-521BC
Color Compact Board Camera
Our miniature 1/4" color CCD board camera has a high resolution output at a 420 line
resolution with a 1.0 lux sensitivity . It features a built-in 3.6mm wide angle lens,
built-in electronic shutter, and internal synchronization. This camera is also available in
a 3.6mm pinhole version that can be found under model number CVC-521PH

Specifications

Resolution
Image Device
Minimum Illumination
Electonic Shutter
White Balance
Lens
Lens Options
Number of Pixels
Operating Temperature
Humidity
Output
Scanning Frequency
Scanning System
Video Output Level
Video S/N Ratio
Power Consumption
Power Supply
Housing
Dimensions
Weight
For more information contact us at:
420 lines
1/4" Interline transfer CCD
.92 lux
Auto 1/100 - 1/100,000 second
Auto White Balance
3.6mm, 74º Hor, 57º Vert.
6, 8mm
512 horizontal x 492 vertical
14º F to 122º F
Within 95 % RH
Video - BNC, Power- DC jack
Horizontal 15.75 kHz vertical 60 Hz
NTSC Color 525 line 60 field/second
1.0 Vp-p 75 ohm
Greater than 46 dB
130 mA
12V DC power supply included (UL and CSA listed)
BCC-20 (optional)
1"L x 1.5"W x 1.5"H
1.8 oz
