V5B3/V5B3M/V5D3/V5D3M/V5T3/V5T3M
USER MANUAL
Thank you for purchasing our product. Speco Technologies is constantly developing and
improving products. We reserve the right to modify product design and specifications
without notice and without incurring any obligation.

Advertisement

loading
Need help?

Need help?

Do you have a question about the V5B3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Speco V5B3

  • Page 1 V5B3/V5B3M/V5D3/V5D3M/V5T3/V5T3M USER MANUAL Thank you for purchasing our product. Speco Technologies is constantly developing and improving products. We reserve the right to modify product design and specifications without notice and without incurring any obligation.
  • Page 2 ■ If the product does not work properly, please contact the dealer or where the product was purchased. Speco Technologies is not responsible for any problems caused by improper operation or repair. Do not expose the unit to heavy stress, violent vibration or long-term exposure to water and humidity during transportation, storage, and/or installation.
  • Page 3: Installation

    You’d better install back the lens cover or lower dome less than 4 hours after removing it. The mounting types of cameras are only for reference. ►Mounting for V5B3/V5B3M 1. Drill the screw holes and the cable hole on the wall according to the drill template.
  • Page 4 Rubber plug 3× 3× V5B3 V5B3M 4. Bracket adjustment. Before adjustment, preview the image of the camera on a monitor and then loosen the lock ring to adjust the view angle of the camera. Tighten the lock ring after the adjustment.
  • Page 5 2. Then remove the trim ring from the gap of the camera as shown below. Trim ring Trim Ring V5D3 V5D3M 3. Loosen the screws to open the lower dome. Then route and connect the cables. 4. Secure the camera to the wall with screws provided as shown below. Rubber Plug 4×...
  • Page 6 Mounting for V5T3/V5T3M ● 1. Drill the screw holes and the cable hole on the wall according to the drill template . (mm) ∅4.5 ∅130.7 ∅107mm ∅119.5 59.7mm ∅118.5mm 120° 120° 120° 29.9mm 120° ∅4.4mm 103.5 mm V5T3 V5T3M 2. Loosen the fixed screw to disassemble the camera. 3.
  • Page 7: Specifications

    Specifications Models V5B3 V5D3 V5B3M Specifications Camera Image Sensor 1/2.5" CMOS Resolution Image size 2944×1656 (16:9) Video Output AHD/TVI/CVI/CVBS (*camera comes defaulted to HD-TVI) Audio Input 1CH built-in MIC 1CH built-in MIC Image System PAL/NTSC Electronic Shutter Auto; 1/50s~1/100000s(PAL);1/60s~1/100000s (NTSC) 32.8~65.6...
  • Page 8 Models V5D3M V5T3M V5T3 Specifications Camera Image Sensor 1/2.5" CMOS Resolution Image size 2944×1656 (16:9) Video Output AHD/TVI/CVI/CVBS (*camera comes defaulted to HD-TVI) Audio Input 1CH built-in MIC Image System PAL/NTSC Electronic Shutter Auto; 1/50s~1/100000s(PAL);1/60s~1/100000s (NTSC) 98.4~164.0 IR Distance (feet) 65.6~98.4 65.6~98.4 TVI: 2944×1656@20fps, 2560×1440@25fps/30fps...
  • Page 9 Model: V5B3/V5B3M/V5D3/V5D3M/V5T3/V5T3M Federal Communications Commission (FCC) Statements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
