5.1 Technical Data

Item#
Specifications
Detector Material
Detector Wavelength Range
Typical Max. Responsivity
Detector Active Area
Transimpedance Gain
Max. Conversion Gain
Output Bandwidth (3dB)
Rise/Fall Time (10% -90%)
CW Saturation Power
Max. Input Power
(Photodiode Damage Threshold))
Minimum NEP (DC - 3dB bandwidth)
Integrated Noise (DC - 3dB bandwidth)
Overall Output Voltage Noise (Typ.)
Electrical Output, Impedance
Maximum Output Voltage
DC-Offset Electrical Output
General Specifications
Size
Power Supply
Operating Temperature Range
Storage Temperature Range
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity
2
) non condensing
Page 8
PDF10C2
InGaAs / PIN
800 - 1700 nm
1.0 A/W @ 1550 nm
2
0.2 mm (Æ 0.5 mm)
11
1 x 10 V/A ±10%
11
1 x 10 V/W ±10%
DC - 20 Hz
19 ms
100 pW
10 mW
7.5 fW/ÖHz
35 fW
RMS
3.5 mV
RMS
BNC, 200 Ω
10 V
< ±75 mV
70.9 mm x 49.9 mm x 22.5 mm
±12V, 250 mA
10°C to 50°C
2)
-25°C to 70°C
