Technical data
Supply / monitored IT system
Supply voltage U
s
Tolerance Supply voltage U
Self consumption, no load at output
Max. operating current I
s
HV voltage range (L+/L-) U
Recommended back-up-fuse
Response values
Response value R
an
Response value hysteresis (DCP)
Undervoltage detection
Undervoltage detection hysteresis
Measuring range
R_iso_corrected
R_iso_original
Measuring range
Insulation: R_iso_neg*
Insulation: R_iso_pos*
Voltage: HV system voltage measurement
Tolerance Voltage: HV system voltage
measurement
Voltage: HV_pos_to_Earth
Tolerance Voltage: HV_pos_to_Earth
Voltage: HV_neg_to_Earth
Tolerance Voltage: HV_neg_to_Earth
Capacity: (capacitance) Measured_Value
Tolerance Capacity: (capacitance)
Measured_Value
Unbalance: Measured_Value
Tolerance Unbalance: Measured_Value
Relative uncertainty of the estimated
measured values of the fast start
measurement: R_iso_status = 0xFC)
30
iso175_D00415_01_M_XXEN/11.2023
s
n
DC 12...24 V
-17...+50 %
≤0.55 W
300 mA
DC 0...1000 V
M 630 mA
30 k...2 M
25 %
0...1000 V
Default setting: 0 V (inactive)
5 %
0...35 M
0...50 M
0...50 M
0...50 M
0...1000 V
±5 % ± 2 V
0...1000 V
±5 % ± 2 V
0...1000 V
±5 % ± 2 V
0...10 F
tbd
0...100 %
tbd
0...-100 %
