CTech™ FlowVPE® System
2. Make sure the Flow Cell is selected in the dropdown menu. Select FC-GxP10-SS for the 10 mm GxP Flow Cell.
!
3. Input the serial number, which is located on the side of the Flow Cell. Make sure to type the serial number
without the hyphen.
4. Line up the dovetail on the Flow Cell with the dovetail on the Detector Module, and gently slide the Flow Cell
into place (see Figure 4). DO NOT FORCE THE CELL IF IT DOES NOT SLIDE EASILY. Remove the Flow Cell and try
again, ensuring both sides of the Flow Cell are engaged with the Detector Module. For assistance in mounting
the Flow Cell properly, refer to General Troubleshooting in the FlowVPE User Manual DOC0096.
2 | analytics-applications@repligen.com | +1 908-707-1009 | ctech.repligen.com
Figure 2. Select Flow Cell from Cell Load/Unload Controls window.
DO NOT CLICK LOAD UNTIL YOU HAVE MOUNTED THE
FLOW CELL AND FIBRETTE.
Figure 3. Serial Number prompt.
Maintenance Guide
!
