4
Technical Specifications
Fig. 13: ekr commander control panel dimensions
4.3

Power Pack

34/162 ekr 500 digital Unit Touch – Installation and Commissioning Manual
Dimensions (details in mm)
Only power packs with the following specifications may be used for
the power supply of the controller including the BST components
connected:
Standard applications
Output voltage
Output power
Applications with CLS CAM 100 object sensor and EMS 21/22
actuator
Output voltage
Output power
The power packs must fulfill the requirements of the IEC 61010-1
for energy limited current circuits. When being used in countries
that have defined deviations to IEC 61010-1, these must also be
observed.
24 V⎓ ± max. 10% (including ripple)
min. 100 W
24 V⎓ ± max. 10% (including ripple)
min. 120 W
