4.2

ekr commander Control Panel

4.2.1

Ambient Conditions

4.2.2

Protection Category

4.2.3 Power Supply
4.2.4 Touchscreen Display
4.2.5 Weight and Dimensions
Ambient conditions
Working temperature
Storage temperature
Humidity during operation
Place of installation
Control panel without controller
Protection category
Power supply from the controller
Voltage
LCD touchscreen display
Resolution
Illumination
ekr commander control panel
Weight
ekr 500 digital Unit Touch – Installation and Commissioning Manual
Technical Specifications
Permissible values
0 to +45 °C
-10 to +70 °C
5% to 90 %, non-condensing
Closed, dry building
IP50
When installing the controller
with the control panel fitted,
the complete unit has
protection category IP54.
24 V⎓
320 x 240 pixels
LED background lighting
Approx. 0.28 kg
4
33/162
