Line and Contrast Sensor CLS Pro 600

Ultrasonic edge sensor US 2010
Fork width
Measuring range
Supply voltage
Current consumption
Ultrasonic frequency
Scan rate
Resolution / Repeatable accuracy* 0.001 mm / 0.05 mm
Linearity
Output signal (analogue mode)
Output signal (digital mode)
Polarity reversal protection
(supply)
Short circuit protection
(analogue output)
Operation display
Electrical connection
Ambient temperature
during operation
Storage temperature
Protection category
Noise emission
Weight
Housing dimensions
RoHS conformity
* in digital mode
Technical specifications, see separate operating manual of the
CLS Pro 600 line and contrast sensor, document number MD.323.
ekr 500 digital Unit Touch – Installation and Commissioning Manual
Technical Specifications
40 mm 70 mm
12 mm 12 mm
12 to 30 V⎓ (including ripple)
40 mA (24 V⎓)
164 kHz
200 Hz
± 0.2 mm
0 to 10 V⎓ (± 2.5%)
CAN bus
yes
yes
LED (2-coloured)
M8 plug, 4-pin
0 to +60 °C
-10 to +70 °C
IP54
< 70 dB
< 400 g < 500 g
See separate product data
sheet
yes
4
