Technical Specifications
36/162 ekr 500 digital Unit Touch – Installation and Commissioning Manual
Optical edge sensor IR 2011
Electrical connection M8 plug, 4-pin
Ambient temperature
during operation
Storage temperature -10 to +70 °C
Protection category
Noise emission
Weight
Housing dimensions
RoHS conformity
* in digital mode
Optical edge sensor IR 2012
Fork width
Measuring range
Supply voltage
Current consumption
Light emitter wave length
Scan rate
Resolution / Repeatable accuracy* 0.001 mm / 0.05 mm
Linearity
Output signal (analogue mode)
Output signal (digital mode)
Polarity reversal protection
(supply)
Short circuit protection
(analogue output)
Operation display
Electrical connection
Ambient temperature
during operation
Storage temperature
Protection category
Noise emission
Weight
Housing dimensions
RoHS conformity
* in digital mode
0 to +60 °C
IP 54
< 70 dB
< 400 g
See separate product data sheet
yes
40 mm
12 mm (±6 mm)
12 to 30 V⎓ (including ripple)
20 mA (24 V⎓)
950 nm
250 Hz
± 0.5 mm
0 to 10 V⎓ (±2.5%)
CAN bus
yes
yes
LED (2-coloured)
M8 plug, 4-pin
0 to +60 °C
-10 to +70 °C
IP 54
< 70 dB
< 500 g
See separate product data
sheet
yes
< 500 g
125 mm
