Message Output "System Ok; Bus Interface - BST ekr 500 digital Installation And Commissioning Manual

4.1.7

Message Output "System OK"

4.1.8

Bus Interface

Terminal strip X11
Voltage
Current
Connection
Connectable components
Terminal strip X8
(plug X102, X103)
Terminal strip X9
(plug X100, X101)
Terminal strip X12
Bus interface
Voltage
Current
Transfer rate
Connection
Terminal strip X101
ekr 500 digital Unit Touch – Installation and Commissioning Manual
Technical Specifications
Max. 24 V∿/⎓
Max. 1 A
Internally on the spring-cage
terminal block
IR 2011, IR 2012
■
(optical edge sensor)
US 2010
■
(ultrasonic edge sensor)
CCD CAM 100, CCD Pro
■
(CCD camera)
Drive Module 160
■
(external output stage for
actuator EMS 23)
CLS Pro 600
■
(line and contrast sensor)
CLS CAM 100
■
(object sensor)
Additional ekr commander
■
control panel
CAN bus extension
24 V⎓ (corresponds to the
supply voltage)
Max. 0.2 A
Max. Σ +24 V⎓: 500 mA
500 kBit/s,
no galvanic isolation
Plugged in from the outside
using a 4-pin micro style M8
connector
If required, the bus interface
can be switched to galvanic
isolation (Jumper JX1)
4
31/162
