AO 026 S-DIAS Analog Output Module Instruction Manual Date of creation: 16.12.2016 Version date: 26.07.2023 Article number: 20-010-026-E...
Page 2
(print, photocopy, microfilm or in any other process) without the express permission. We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsi- ble for technical or printing errors in the handbook and assumes no responsibility for damages that occur through...
Page 3
AO 026 with 2 outputs (voltage/current switchable) The S-DIAS AO 026 analog output module has two galvanically isolat- ed outputs with a resolution of 16 bits, which can be switched between voltage and current outputs. The analog outputs are powered by an external +24 V supply.
AO 026 S-DIAS ANALOG OUTPUT MODULE Contents Introduction ................5 Target Group/Purpose of this Operating Manual ...... 5 Important Reference Documentation ......... 5 Contents of Delivery ..............5 Basic Safety Directives ............6 Symbols Used ................6 Disclaimer ..................8 General Safety Directives ............
Page 5
S-DIAS ANALOG OUTPUT MODULE AO 026 Connector Layout ..............19 Status LEDs ................. 20 Applicable Connectors ............... 20 Label Field ................... 21 Wiring ..................22 Wiring Example ................22 Notes .................... 23 Assembly/Installation ............24 Check Contents of Delivery ............24 Mounting ..................
Page 6
AO 026 S-DIAS ANALOG OUTPUT MODULE 14.2 Repair ................... 31 15 Disposal ..................31 16 Hardware Class AO026 ............32 16.1 General ..................33 16.2 Analog Outputs ................34 16.3 Communication Interfaces ............34 16.4 Internal Properties ..............35 Page 4 26.07.2023...
General knowledge of automation technology is required. Further help and training information, as well as the appropriate accessories can be found on our website www.sigmatek-automation.com. Our support team is happily available to answer your questions. Please see our website for our hotline number and business hours.
AO 026 S-DIAS ANALOG OUTPUT MODULE Basic Safety Directives Symbols Used The following symbols are used in the operator documentation for warning and danger messages, as well as informational notes: DANGER Danger indicates that death or serious injury will occur, if the speci- fied measures are not taken.
Page 9
S-DIAS ANALOG OUTPUT MODULE AO 026 INFORMATION Information Provides important information on the product, handling or relevant sections of the documentation, which require atten- tion. 26.07.2023 Page 7...
It does not guarantee properties under the warranty. Please thoroughly read the corresponding documents and this operat- ing manual before handling a product. SIGMATEK GmbH & Co KG is not liable for damages caused through, non-compliance with these instructions or applicable regulations.
S-DIAS ANALOG OUTPUT MODULE AO 026 General Safety Directives The Safety Directives in the other sections of this operating manual must be observed. These instructions are visually emphasized by symbols. INFORMATION According to EU Directives, the operating manual is a component of a product.
AO 026 S-DIAS ANALOG OUTPUT MODULE CAUTION Handle the device with care and do not drop or let fall. Prevent foreign bodies and fluids from entering the device. The device must not be opened! Manipulez l’appareil avec précaution et ne le laissez pas tomber.
The product was constructed in compliance with the following European Union directives and tested for conformity. 3.1.1 EU Conformity Declaration EU Declaration of Conformity The product AO 026 conforms to the following European directives: • 2014/35/EU Low-voltage Directive • 2014/30/EU Electromagnetic Compatibility (EMC Directive) •...
S-DIAS ANALOG OUTPUT MODULE AO 026 Technical Data Analog Output Voltage Specifications Number of channels -10 … +10 V Output range 0 ... +10 V Output value -30,000 ... +30,000 0 ... +60,000 -10.8 … +10.8 V 0 … +10.8 V Output voltage over range 0 …...
AO 026 S-DIAS ANALOG OUTPUT MODULE Analog Output Current Specifications Number of channels Output range 0-20 mA 4-20 mA Output value 0-60,000 12,000-60,000 Output range over range 0-20.2 mA 3.8-20.2 mA Output value over range 0-60,600 11,400-60,600 Resolution current 16-bit (ca. 0.3 µA/LSB) ≥...
S-DIAS ANALOG OUTPUT MODULE AO 026 Electrical Requirements External +24 V supply +18-30 V DC Current consumption of the +24 V typically 45 mA maximum 55 mA supply without load on the analog outputs Current consumption of the +24 V...
Page 18
AO 026 S-DIAS ANALOG OUTPUT MODULE Page 16 26.07.2023...
S-DIAS ANALOG OUTPUT MODULE AO 026 Miscellaneous Article number 20-010-026 Standard UL (in preparation), UKCA Environmental Conditions Storage temperature -20 ... +85 °C Ambient temperature 0 ... +55 °C Humidity 0-95 %, non-condensing Installation altitude above sea 0-2000 m without derating level >...
S-DIAS ANALOG OUTPUT MODULE AO 026 Connector Layout INFORMATION The connections of the +24 V supply (X3: pin 1 and pin 2) or the GND supply (X3: pin 3 and pin 4) are internally bridged. To supply the mod- ule, only one connection to a +24 V pin (pin 1 or pin 2) and a GND pin (pin 3 or pin 4) is required.
AO 026 S-DIAS ANALOG OUTPUT MODULE Status LEDs green Module Status module active no supply available BLINKING (5 Hz) no communication yellow User can be set from the application (e.g. the module LED can be set to blinking through the...
S-DIAS ANALOG OUTPUT MODULE AO 026 Label Field Manufacturer Weidmüller Type MF 10/5 CABUR MC NE WS Weidmüller article number 1854510000 Compatible printer Weidmüller Type Printjet Advanced 230V Weidmüller article number 1324380000 26.07.2023 Page 21...
S-DIAS ANALOG OUTPUT MODULE AO 026 Notes The signals recorded by the analog modules are very small, as compared to the digital signals. To ensure error-free operation, a careful wiring method must be followed: • The 0 V connection of the supply voltage must be connected with the 0 V collection point over the shortest route possible.
AO 026 S-DIAS ANALOG OUTPUT MODULE Assembly/Installation Check Contents of Delivery Ensure that the contents of the delivery are complete and intact. See chapter Contents of Delivery. INFORMATION On receipt and before initial use, check the device for damage. If the device is damaged, contact our customer service and do not install the device in your system.
S-DIAS ANALOG OUTPUT MODULE AO 026 Mounting The S-DIAS modules are designed for installation into the control cabinet. To mount the modules a DIN-rail is required. The DIN rail must establish a conductive connection with the back wall of the control cabinet. The individual S-DIAS modules are mounted on the DIN rail as a block and secured with latches.
Page 28
AO 026 S-DIAS ANALOG OUTPUT MODULE Recommended minimum distances of the S-DIAS modules to the surrounding components or control cabinet wall: a, b, c … distances in mm (inches) Page 26 26.07.2023...
S-DIAS ANALOG OUTPUT MODULE AO 026 10 Addressing 10.1 Address Mapping Overview Address Size Description (hex) (bytes) 0000 Cyclic Data for Firmware 0080 cCyclic Data for the HW class 0100 CFG for the Firmware 0180 CFG/version for the HW class...
Page 30
AO 026 S-DIAS ANALOG OUTPUT MODULE info (special-purpose or status bits) Bit 0 PMB mode 0104 0 ... normal mode 1 … PMB Mode -> output without adjustment data Bit 1 boot loader/update request 0105 reserved selection of the analog output 0 …...
S-DIAS ANALOG OUTPUT MODULE AO 026 11 Supported Cycle Times 11.1 Cycle Times below 1 ms (in µs) V1.00 11.2 Cycle Times equal to or above 1 ms (in ms) V1.00 V1.00 26.07.2023 Page 29...
AO 026 S-DIAS ANALOG OUTPUT MODULE 12 Transport/Storage INFORMATION This device contains sensitive electronics. During transport and stor- age, high mechanical stress must therefore be avoided. For storage and transport, the same values for humidity and vibration as for operation must be maintained! Temperature and humidity fluctuations may occur during transport.
S-DIAS ANALOG OUTPUT MODULE AO 026 14 Maintenance INFORMATION During maintenance as well as servicing, observe the safety instruc- tions from chapter 2 Basic Safety Directives. 14.1 Service This product was constructed for low-maintenance operation. 14.2 Repair INFORMATION In the event of a defect/repair, send the device with a detailed error description to the address listed at the beginning of this document.
Hardware Class AO026 for the S-DIAS AO026 Analog Output Module This hardware class is used to control the AO 026 hardware module. The module has ±10 V, 0-10 V or 0-20 mA, 4-20 mA analog outputs. More information on the hardware can be found in the module documentation.
S-DIAS ANALOG OUTPUT MODULE AO 026 16.1 General Class State State This server shows the actual status of the hardware class. Device ID State The device ID of the hardware module is shown in this server. FPGA Version State FPGA version of the module in 16#XY (e.g. 16#10 = version 1.0).
AO 026 S-DIAS ANALOG OUTPUT MODULE 16.2 Analog Outputs Analog Output Output Analog output [1-2] can be set over the Write() method. Values are output [1-2] depending on configuration. With the Analog Output Config 4-7, the output value can be overridden with the overrange settings.
S-DIAS ANALOG OUTPUT MODULE AO 026 16.4 Internal Properties The values for the analog output are transmitted as 16-bit value in a range of ±30,000 resp.0-60,000 increments. To be able to use the full resolution of the DAC values for the minimum and maximum value settings are needed which allow 60,000 increments.
Page 38
AO 026 S-DIAS ANALOG OUTPUT MODULE Documentation Changes Change date Affected Chapter Note page(s) 11.01.2017 3, 4 1.1 Analog Output Voltage Formulation of analog precision Specifications 1.1 Analog Output Current Specifications 01.02.1017 3, 4 1.1 Analog Output Voltage Refresh time of all channels Specifications 1.1 Analog Output Current...
