Sleep
If the robot is paused for over 10 minutes, it
will go to sleep, and the power indicator will
flash every few seconds. Press any button
to wake the robot up.
Notes:
• The robot will not go to sleep when it is charging.
• The robot will automatically shut down if left in sleep
mode for more than 12 hours.
DND Mode
The default Do Not Disturb (DND) period
is from 22:00 to 08:00. You can use the
app to disable the DND mode or modify
the DND period. When DND mode is
activated, the robot will not automatically
resume cleanup, the power indicator
light will dim, and the volume of the
voice prompts will lower.
Child Lock
Press and hold the button to enable/
disable the child lock. You can also set it in
the app. Once enabled, the robot will not
react to button presses when it is
stationary. When the robot is cleaning or
docking, press any button to stop it.
Charging
After cleaning, the robot will automatically
return to the dock to charge.
In Pause mode, press the button to send
the robot back to the dock. The power
indicator will pulse as the robot charges.
Note: If the robot fails to find the dock, it will automatically
return to its starting location. Place the robot on the dock
manually to recharge.
Error
If an error occurs, the power indicator light
on the robot will flash red or status
indicator light on the dock will be steady
red. A pop-up notification will receive in the
app and a voice alert may sound.
Notes:
• The robot will go to sleep automatically if left in a
malfunctioning state for over 10 minutes.
• Placing a malfunctioning robot on the dock manually will
end the current cleanup.
System Reset
If the robot does not respond when a
button is pressed or cannot be turned off,
reset the system. Press the Reset button,
and the robot will reset automatically.
Note: After resetting the system, scheduled cleaning, WiFi,
etc. will be restored to factory settings.
Restore Factory Settings
If the robot does not function properly after a
system reset, switch it on. Press and hold the
button and at the same time, press the
Reset button until you hear the "Restoring
factory settings" voice prompt. The robot
will then be restored to factory settings.
Routine
C
Maintenance
Main Brushes
C1
* Clean every 2 weeks and replace every 6-12 months.
C1-1—Main Brush
C1-2—Main Brush Cover
C1-3—Latches
09
C1-4—Main Brush Bearing
C1-5—Main Brush Caps
C1-6— Turn over the robot and press the
latches to remove the main brush cover.
C1-7— Remove the main brush and pull out
the main brush bearing.
C1-8— Pull out the main brush caps.
C1-9— After removing the tangled hair or dirt
at both ends of the main brush,
reinstall it, press on the main brush
cover to lock it in place.
Notes:
• Main brush should be wiped down with a wet cloth and
left to dry away from direct sunlight.
• Do not use corrosive cleaning fluids or disinfectants to
clean the main brush.
Side Brush
C2
* Clean monthly and replace every 3-6 months.
1. Unscrew the side brush screw.
2. Remove and clean the side brush.
Reinstall the brush and tighten the screw.
Omnidirectional Wheel
C3
* Clean as required.
C3-1— Use a tool, such as a small screwdriver,
to pry out the axle and take out the
wheel.
Note: The omnidirectional wheel bracket cannot be removed.
C3-2— Rinse the wheel and the axle with
water to remove any hair and dirt.
Dry and reattach the wheel, pressing
it firmly in place.
Main Wheels
C4
* Clean monthly.
Clean the main wheels with a soft, dry cloth.
