- Page 1 Sun™ Ultra™ 30/60/80 Systems Rackmount Installation Guide Sun Microsystems, Inc. 901 San Antonio Road Palo Alto, CA 94303-4900 USA 650-960-1300 fax 650-969-9131 Part No. 806-1453-10 July 1999, Revision A Send comments about this document to: docfeedback@sun.com...
- Page 2 Sun, Sun Microsystems, the Sun logo, AnswerBook2, Java, The Java Coffee CUp logo, Ultra , Sun Enterprise, and Solaris are trademarks, registered trademarks, or service marks of Sun Microsystems, Inc. in the U.S. and other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc.
-
Page 3: Table Of Contents
Contents Sun Ultra 30/60/80 Systems Rackmount Installation Guide 1 Preparing the Site 1 Preparing the Rackmounting Tray 3 Preparing the Ultra 30/60 System 10 Installing the Ultra 30/60 System 14 Preparing the Ultra 80 System 20 Installing the Ultra 80 System 24... - Page 4 Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999...
-
Page 5: Sun Ultra 30/60/80 Systems Rackmount Installation Guide
Sun Ultra 30/60/80 Systems Rackmount Installation Guide This document describes how to install a Sun™ Ultra™ 30, Ultra 60, or Ultra 80 workstation (the system) into a rack configuration using the optionally purchased rackmounting kit. Preparing the Site Prior to rackmounting the system, ensure you have adequate power, ventilation, and environmental controls to support your rackmounted system. - Page 6 Load bearing capacity The rack must firmly support the weight of up to five Ultra 80 systems (at 66 lbs, 30 kg each) or six Ultra 30/60 systems (at 45 lbs, 20 kg each), plus the weight of each associated rackmounting kit.
-
Page 7: Preparing The Rackmounting Tray
Left rear rail rear mounting bar Ultra 80 Left front rail rear mounting bar Tray Right rear rail Left front bracket Manual Right front rail Right front bracket Fasteners Rackmounting Kit Inventory FIGURE 1 Sun Ultra 30/60/80 Systems Rackmount Installation Guide... - Page 8 A rack-installed system requires clearance to allow for the rackmounting tray, the system, and air flow space. An Ultra 80 requires seven rackmount units (22 holes, 12.3 inches, 31.1 cm). An Ultra 30 or Ultra 60 requires six rackmount units (19 holes, 10.6 inches, 26.9 cm).
- Page 9 3. Unfasten the mounting rails ( FIGURE 3 The rails are fastened together for shipping purposes. Using a No. 2 Phillips screwdriver unfasten the screw holding the front and rear rail pieces together. Unfastening Mounting Rails FIGURE 3 Sun Ultra 30/60/80 Systems Rackmount Installation Guide...
- Page 10 Caution – If you are installing multiple systems, install the lower rackmounting kits (and systems) first, then work toward the top. This prevents the rack from being top- heavy and tipping. Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999...
- Page 11 Horizontally align the right side rail assembly with the left side rail. d. Using four of the provided screws, fasten the right rail assembly to the right side of the rack. Installing Rails into the Rack FIGURE 5 Sun Ultra 30/60/80 Systems Rackmount Installation Guide...
- Page 12 Caution – Do not place the system on the tray before the tray is in place and fully secured. The rails are not designed to support the weight of a system on an extended tray. Do not use the tray as a “sliding shelf”. Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999...
- Page 13 Using two of the provided screws, fasten the front of the tray to the rails. The screws should be fed through the tray flange into the rail flange from the top. Fastening the Mounting Tray to the Mounting Rails FIGURE 7 Sun Ultra 30/60/80 Systems Rackmount Installation Guide...
-
Page 14: Preparing The Ultra 30/60 System
1. Unpack or disconnect your system ( FIGURE 8 Refer to your system documentation for specific directions on powering off and disconnecting your system. The power switch is the same for an Ultra 30 and an Ultra 60. Power Switch on an Ultra 60 System FIGURE 8 Sun Ultra 30/60/80 Systems Rackmount Installation Guide •... - Page 15 To power off the Ultra 30/60 system: Caution – Prior to turning off the system power, exit from the operating system. Failure to do so may result in data loss. a. Back up system files and data. b. Halt the system.
- Page 16 2. Lay the system on its side ( FIGURE 9 Facing the front of the system, tip the unit to the right so the feet are to the left. Ultra 30/60 System Placed Horizontally FIGURE 9 Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999...
- Page 17 3. Remove the system feet ( FIGURE 10 Using the No. 2 Phillips screwdriver, unfasten the screws attaching the feet to the system. Set the feet and screws aside. Removing the Ultra 30/60 System Feet FIGURE 10 Sun Ultra 30/60/80 Systems Rackmount Installation Guide...
-
Page 18: Installing The Ultra 30/60 System
3. Slide the system back until it is slightly behind the front of the rackmounting tray FIGURE 11 Placing the Ultra 30/60 System in the Rack FIGURE 11 Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999... - Page 19 Place the bracket so it fits snugly above the system, while maintaining alignment with the rack rail holes. 7. Using two of the provided screws, fasten the right front bracket to the rack FIGURE 12 Fastening the Front Brackets FIGURE 12 Sun Ultra 30/60/80 Systems Rackmount Installation Guide...
- Page 20 8. Slide the system forward on the rackmounting tray until it is tight against the front brackets ( FIGURE 13 Sliding the Ultra 30/60 System into the Front Brackets FIGURE 13 Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999...
- Page 21 These screws do not fasten to the system. Rear bracket overlapping system Fastening the Ultra 30/60 System to the Mounting Tray FIGURE 14 Sun Ultra 30/60/80 Systems Rackmount Installation Guide...
- Page 22 10. Store the system feet ( FIGURE 15 Using the screws that originally fastened the feet to the system, fasten the spare feet to the rackmounting tray. Storing Ultra 30/60 System Feet FIGURE 15 Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999...
- Page 23 FIGURE 16 Your system is ready for you to continue with your system-specific installation processes. Refer to your system documentation for further instructions. Ultra 30/60 System Installed and Ready for Cabling FIGURE 16 Sun Ultra 30/60/80 Systems Rackmount Installation Guide...
-
Page 24: Preparing The Ultra 80 System
Caution – Prior to turning off the system power, exit from the operating system. Failure to do so may result in data loss. a. Back up system files and data. b. Halt the system. Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999... - Page 25 Facing the back of the system, tip the unit to the left so the feet are to the right. Note – Place the system on the power supply side. Do not place the system on the access panel side. Sun Ultra 30/60/80 Systems Rackmount Installation Guide...
- Page 26 3. Remove the three screws from the base of the power supply at the back of the system. Set the screws aside ( FIGURE 18 Access panel Power supply System feet Removing the Power Supply Screws FIGURE 18 Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999...
- Page 27 FIGURE 19 Face the open channel of the mounting bar downward. Feed the power supply screws through the mounting bar’s open channel cutouts. Fastening the Mounting Bar to the Ultra 80 System FIGURE 19 Sun Ultra 30/60/80 Systems Rackmount Installation Guide...
-
Page 28: Installing The Ultra 80 System
2. Facing the front of the system and the front of the rack, place the system on the mounting tray. Caution – The system weighs over 66 pounds (29.5 kg). Always ensure that two people lift the system. Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999... - Page 29 3. Slide the system back until it is flush with the rear flanges on the mounting tray FIGURE 20 Placing the Ultra 80 System in the Rack FIGURE 20 Sun Ultra 30/60/80 Systems Rackmount Installation Guide...
- Page 30 These screws do not fasten to the system. They fasten to the mounting bar. Mounting bar attached to Mounting tray system rear flange Fastening the Ultra 80 System to the Mounting Tray FIGURE 21 Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999...
- Page 31 Place the bracket so it fits snugly above the system, while maintaining alignment with the rack rail holes. 8. Using two of the provided screws, fasten the right front bracket to the rack FIGURE 22 Fastening the Front Brackets FIGURE 22 Sun Ultra 30/60/80 Systems Rackmount Installation Guide...
- Page 32 Your system is ready for you to continue with your system-specific installation processes. Refer to your system documentation for further instructions. Ultra 80 System Installed and Ready for Cabling FIGURE 23 Sun Ultra 30/60/80 Systems Rackmount Installation Guide • July 1999...
