- Page 1 Sun Ultra™ 80 Rack Mount Installation Guide Sun Microsystems, Inc. 901 San Antonio Road Palo Alto, CA 94303-4900 USA 650-960-1300 fax 650-969-9131 Part No. 805-7959-10 May 1999, Revision A Send comments about this document to: docfeedback@sun.com...
- Page 2 Sun, Sun Microsystems, the Sun logo, AnswerBook2, Java, The Java Coffee CUp logo, Ultra , Sun Enterprise, and Solaris are trademarks, registered trademarks, or service marks of Sun Microsystems, Inc. in the U.S. and other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc.
-
Page 3: Table Of Contents
Contents Sun Ultra 80 Rack Mount Installation Guide 5 Preparing Your Site 5 Preparing to Install 7 Preparing the Rack-Mounting Tray 11 Preparing the System 15 Installing the System 17 Contents... - Page 4 Sun Ultra 80 Rack Mount Installation Guide • May 1999...
-
Page 5: Sun Ultra 80 Rack Mount Installation Guide
Sun Ultra 80 Rack Mount Installation Guide This document describes how to install a Sun Ultra™ 80 workstation (the system) into a rack configuration using the optionally purchased rack-mounting kit. Preparing Your Site Prior to rack-mounting your system, ensure you have adequate power, ventilation, and environmental controls to support your rack-mounted system. - Page 6 Fire containment The rack enclosure must meet Underwriters Laboratories, Inc. and TUV Rheinland of N.A. requirements for fire containment. Sun Ultra 80 Rack Mount Installation Guide • May 1999...
-
Page 7: Preparing To Install
Each item is a quantity of one, except the fasteners. There are 22 screw-type fasteners. Left rear rail Mounting bar Left front rail Tray Right rear rail Left front bracket Manual Right front rail Right front bracket Fasteners Rack-Mounting Kit Inventory FIGURE 1 Sun Ultra 80 Rack Mount Installation Guide... - Page 8 Caution – Pressing the power switch does not remove all power from the system; a trickle voltage remains in the power supply. To remove all power from the system, disconnect the power cord. Sun Ultra 80 Rack Mount Installation Guide • May 1999...
- Page 9 The system fans are not spinning. e. Turn off the power to the monitor. f. Disconnect the power cords. g. Disconnect cables to any peripheral equipment. 3. Set aside all cabling and peripherals. Sun Ultra 80 Rack Mount Installation Guide...
- Page 10 A typical rack 72-inch (183-cm) in height can support up to five rack-mounted systems. One rack-mount units: 1.75 inches Seven rack-mount units: 12.25 inches Mounting Rack FIGURE 3 Sun Ultra 80 Rack Mount Installation Guide • May 1999...
-
Page 11: Preparing The Rack-Mounting Tray
Place the right front rail into the right rear rail. f. Using the completed left rail pair as a template, measure the length required for the right rail pair, adjust and fasten. Left Rear Right Front Assembling the Mounting Rails FIGURE 4 Sun Ultra 80 Rack Mount Installation Guide... - Page 12 Align the right side rail assembly with the left side rail. d. Using four of the provided screws, fasten the right rail assembly to the right side of the rack. Installing Rails into the Rack FIGURE 5 Sun Ultra 80 Rack Mount Installation Guide • May 1999...
- Page 13 Caution – Do not place the system on the tray before the tray is in place and fully secured. The rails are not designed to support the weight of a system on an extended tray. Do not use the tray as a ‘sliding shelf’. Sun Ultra 80 Rack Mount Installation Guide...
- Page 14 Using two of the provided screws, fasten the front of the tray to the rails. The screws should be fed through the tray flange into the rail flange from the top. Fastening the Mounting Tray to the Mounting Rails FIGURE 7 Sun Ultra 80 Rack Mount Installation Guide • May 1999...
-
Page 15: Preparing The System
2. Remove the three screws from the base of the power supply at the back of the system. Set the screws aside ( FIGURE 8 Access panel Power supply System feet Removing the Power Supply Screws FIGURE 8 Sun Ultra 80 Rack Mount Installation Guide... - Page 16 Face the open channel of the mounting bar downward. Feed the power supply screws through the mounting bar’s open channel cutouts. Fastening the Mounting Bar to the System FIGURE 9 Sun Ultra 80 Rack Mount Installation Guide • May 1999...
-
Page 17: Installing The System
2. Facing the front of the system and the front of the rack, place the system on the mounting tray. Caution – The system weighs over 65 pounds. Always ensure that two people lift the system. Sun Ultra 80 Rack Mount Installation Guide... - Page 18 3. Slide the system back until it is flush with the rear flanges on the mounting tray FIGURE 10 Placing the System in the Rack FIGURE 10 Sun Ultra 80 Rack Mount Installation Guide • May 1999...
- Page 19 These screws do not fasten to the system. They fasten to the mounting bar. Mounting bar attached to Mounting tray system rear flange Fastening the System to the Mounting Tray FIGURE 11 Sun Ultra 80 Rack Mount Installation Guide...
- Page 20 8. Using two of the provided screws, fasten the right front bracket to the rack FIGURE 12 Fastening the Left and Right Front Brackets FIGURE 12 Sun Ultra 80 Rack Mount Installation Guide • May 1999...
- Page 21 9. Connect power and cables as needed ( FIGURE 13 Your system is ready for you to continue with your system-specific installation processes. Refer to your system documentation for further instructions. System Installed and Ready for Cabling FIGURE 13 Sun Ultra 80 Rack Mount Installation Guide...
- Page 22 Sun Ultra 80 Rack Mount Installation Guide • May 1999...
