MULTIQUIP PRO12C Operation Manual page 25

DUMPING
1. Push the hydraulic dump lever (Figure 26) forward to
place the drum in the dump position (Figure 27).
PULL TO
RETURN
Figure 26. Hydraulic Dump Lever
Figure 27. Hydraulic Dump
PRO12C HYDRAULIC MIXER • OPERATION MANUAL — REV. #0 (07/16/20) — PAGE 25
PUSH
TO DUMP
HYDRAULIC
DUMP LEVER
2. Pull the hydraulic dump lever backward to return the
drum to the upright position.
WARNING
When rotating the mixing drum from the dump position to
the upright position, keep hands clear of the safety grate.
The possibility exists of hands or fingers being crushed.
STOPPING THE MIXER (GASOLINE ENGINE)
Normal Shutdown
1. Place the throttle lever in the IDLE (slow) position,
and let the engine idle for 3–5 minutes. See Figure 28.
THROTTLE
Figure 28. Throttle Lever (IDLE)
OPERATION
LEVER
RUN IDLE
