Specifications - MULTIQUIP PRO12C Operation Manual

Capacity
Bag Capacity
Operating Weight
Maximum Aggregate Size
Adjustable Drum Discharge Height
Drive System
Dump Action
Model
Type
Bore × Stroke
Displacement
Max. Output
Continuous Output
Fuel Tank Capacity
Fuel
Lube Oil Capacity
Speed Control Method
Starting Method
Model
Enclosure
Horsepower
Input Voltage (VAC)
Phase
Frequency (Hz)
Max. Output @ RPM
Full Load Amps
Weight
Dimensions (L × W × H)
PRO12C HYDRAULIC MIXER • OPERATION MANUAL — REV. #0 (07/16/20) — PAGE 11
Table 1. Mixer Specifications
Table 2. Engine Specifications
Honda GX390RT2-QNB2
Air-cooled, 4-stroke, horizontal-shaft, gasoline engine
88 mm × 64 mm (3.46 in. × 2.51 in.)
11.7 hp @ 3,600 rpm
Approx. 18.9 liters (5.0 US gallons)
Centrifugal flyweight type
Table 3. Electric Motor Specifications
Teco Westinghouse Model 3414
TEFC
5
230
1
60
5 hp @ 1,745
30
46.7 kg (103 lb.)
458 × 223.5 × 266.7 mm
(18.03 × 8.8 × 10.5 in.)

SPECIFICATIONS

340 liters (12.0 cu. ft.)
3–4 bags
716.7 kg (1,580 lb.)
25.4 mm (1 in.)
Up to 1,079.5 mm (42.5 in.)
Hydraulic
Hydraulic
389 cc (23.7 cu. in.)
9.0 hp @ 3,600 rpm
Unleaded gasoline
1.1 liters (1.16 qt.)
Electric start
Teco Westinghouse Model 3481
5 hp @ 1,725
12.24/6.12
46.7 kg (103 lb.)
401 × 223.5 × 266.7 mm
(15.79 × 8.8 × 10.5 in.)
TEFC
5
230/460
3
60
