Setting Up Ai Events - Amcrest AMDV5M32-6TB Quick Start Manual

Start by making sure the Enable toggle switch is toggled to the on position. Then, enter the SMTP
Server which, for Gmail, is: "smtp.gmail.com". The port number will be: "465".
In the Username field, enter your new Gmail account's address. For example:
"amcrestemailsme@gmail.com". Then, enter the password for this account in the Password field.
In the Email Address field, enter your own personal email account's address. For example:
"amcrestemailsme@gmail.com". In the Sender field, enter your email address again.
Make sure the toggle switch for the Attachment is toggled to the on position. Then, make sure
the Encryption Type field is set to "SSL".
Finally, click Apply in the bottom-right of this window to save all your settings.
11. Now, we want to make sure the email setup is working properly. To do this, click Test in the
bottom-left. If the setup was successful, you will get the "Mail Test Normal" pop-up message after
clicking Test.
12. Next, check your new Gmail account to see if you received the email test. Whenever your
camera detects motion, you will get email alerts sent to your personal email from this new Gmail
account. This will include an email with a snapshot of what was seen when motion detection was
triggered.

Setting Up AI Events

This section will cover the basic setup of AI events provided by the DVR. The features listed in the
AI menu include SMD (Smart Motion Detection),
SMD which function independently in the system.
1. Log into your DVR and on the Main Menu, click on AI.
2. Select a feature from the AI Mode menu. Please note, after an AI mode is selected, the DVR
will reboot, please allow the device to reboot once an AI is selected.
SMD – Allows the device to use smart motion detection to detect between human and motor
vehicles.
Face Detection & Recognition - Face detection is used to allow your device to detect and record
face image events. Face recognition is used in conjunction with face detection to locate and
determine facial similarities detected by the system. Images are registered in a face library, by the
user, and accessed via a face recognition smart search tool that is built into the DVR.
IVS&SMD –
IVS stands for intelligent video system analytics and are primarily used for parameter
protection. The DVR currently has 2 built-in IVS features available (Tripwire and Intrusion).
Motion Detection (SMD) uses an advanced algorithm to differentiate human and vehicular shapes
within a scene and send alarms only when a person or vehicle is detected.
SMD cannot be activated on the same channel.
When Using IVS&SMD
Model
AMDV5M16
3. Select a parameter from the AI Mode menu. Click ok to reboot the DVR, once the DVR has
finished rebooting, navigate back to the AI menu. The parameter will be highlighted and ready to
configure.
Face Detection & Recognition, as well as IVS &
Limitation
Max of 2 IVS channels
1 channel of IVS and 8 Channels of SMD
16 channels of SMD
Smart
Please note, IVS and
21
