Model No. PFTL90924.1
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
REGISTER YOUR
PRODUCT
To register your product and
activate your warranty today,
go to my.proform.com.
MEMBER CARE
For service at any time, go to
my.iFIT.com or scan the QR code.
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro-Form Carbon TLX PFTL90924.1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for iFIT Pro-Form Carbon TLX PFTL90924.1

Summary of Contents for iFIT Pro-Form Carbon TLX PFTL90924.1

  • Page 1 To register your product and activate your warranty today, go to my.proform.com. MEMBER CARE For service at any time, go to my.iFIT.com or scan the QR code. Please do not contact the store. CAUTION Read all precautions and instructions in this manual before using this equipment.

  • Page 2: Table Of Contents

    Note: The decals may not be shown at actual size. PROFORM and IFIT are registered trademarks of iFIT Inc. App store is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks of Google LLC. The Bluetooth word mark ®...

  • Page 3: Important Precautions

    To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. iFIT assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 19. Read, understand, and test the emergency 26. When folding or moving the treadmill, make stop procedure before using the treadmill sure that the storage latch is holding the (see HOW TO TURN ON THE CONSOLE on frame securely in the storage position. Do page 17).

  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new PROFORM reading this manual, please see the front cover of this ® CARBON TLX treadmill. The CARBON TLX treadmill manual. To help us assist you, note the product model provides an impressive selection of features designed number and serial number before contacting us.

  • Page 7: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 8: Assembly

    ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 7. • Place all parts in a cleared area and remove the • Left parts are marked “L” or “Left” and right parts packing materials. Do not dispose of the packing are marked “R”...
  • Page 9 3. Locate the Upright Wire (74) on the right side of the Upright Base (81). Remove the wire tie (not shown) securing the Upright Wire to the Upright Base as shown. Next, identify the Right Upright (73), and have a second person hold it near the Upright Base (81).
  • Page 10 5. Do not pinch the ground wire (31) during this step. Locate the small tab (E) on the Crossbar (69). Hold the Crossbar between the Uprights (72, 73), with the tab in the slot (F) in the Left Upright. Attach the Crossbar (69) with four 5/16" x 3/4" Screws (2) and four 5/16"...
  • Page 11 7. Make sure that the Ground Wire (31) is in front of the Crossbar (69) as shown. Do not pinch the Ground Wire during this step. Set the Console Base (84) on the Uprights (72, 73). Attach the Console Base (84) with the four 5/16"...
  • Page 12 To see a short video about how to connect wires, scan the QR code or go to my.iFIT.com. Next, connect the Ground Wire (31) to the console ground wire (J).
  • Page 13 12. Remove the 5/16" Nut (23), the two 3/8" Thrust Washers (16), and the 5/16" x 1 1/2" Bolt (19) from the Upright Base (81). Note: If either of the 5/16" Bushings (3) comes out, reinsert it. Next, orient the Storage Latch (71) as shown and attach it to the bracket on the Upright Base (81) with the 5/16"...
  • Page 14 Console (83). Note: If you do not have a smartphone or tablet, use your computer to go to iFIT.com/activate for an alternate way to activate the Console (83). If you do not have a computer, please see the Member Care contact information on page 25.

  • Page 15: How To Plug In The Power Cord

    HOW TO PLUG IN THE POWER CORD USE A SURGE SUPPRESSOR overloading the circuit, do not plug other electrical devices, except for low-power devices such as cell Your treadmill, like other electronic equipment, can be phone chargers, into the surge suppressor or into damaged by sudden voltage changes in your home’s an outlet on the same circuit.

  • Page 16: How To Use The Treadmill

    To turn on and turn off the console, see page 17. To console will display continuous exercise feedback. use the manual mode, see page 18. To use an iFIT workout, see page 20. To change console settings, You can even monitor your heart rate when you use a see page 21.
  • Page 17 HOW TO TURN ON THE CONSOLE switch into the reset position, the demo mode is turned on. To turn off the demo mode, hold down IMPORTANT: If the treadmill has been exposed to the Stop button for a few seconds. If the display cold temperatures, allow it to warm to room tem- remains lit, see HOW TO CHANGE CONSOLE perature before you turn on the console.
  • Page 18 HOW TO USE THE MANUAL MODE 5. Change the incline as desired. You can change the incline of the treadmill in the 1. Insert the key into the console. following ways: See HOW TO TURN ON THE CONSOLE on page 17. Incline increase and decrease buttons—Each time you press a button, the incline will gradually change until it reaches the selected incline setting.
  • Page 19 Press the Display Next, press the +/- button (G) to add or remove that button (D) repeat- workout information from the scan cycle. When edly to view the workout information is added, its indicator will desired workout turn on in the display. When workout information information in the is removed, its indicator will turn off.
  • Page 20 4. Select an iFIT workout. The console offers access to a large and varied library In the iFIT app, touch the buttons at the bottom of of iFIT workouts when you download the iFIT app to the screen to select either the home screen (Home your smart device and connect it to the console.
  • Page 21 To disconnect your smart device from the console, first select the disconnect option in the iFIT app. 3. Change settings as desired. Then, press and hold the iFIT Sync button on the console until the LED on the console turns solid Unit of Measurement—The currently selected unit green.
  • Page 22 Incline System Calibration—The letters CAL will Total Time—The word TIME will appear in the appear in the display. If the incline system is not display. The display will show the total number of functioning properly, it may need to be calibrated. hours that the treadmill has been used.

  • Page 23: Fcc Information

    Adjust To connect your Bluetooth Smart heart rate moni- tor to the console, press the iFIT Sync button on the the volume level using console; the console pairing number will appear in the the Vol increase and display.

  • Page 24: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL Before moving the treadmill, fold it as described at the Before folding the treadmill, adjust the incline of left. CAUTION: Make sure that the storage latch is in the treadmill to 0% to avoid damaging the treadmill.

  • Page 25: Maintenance And Troubleshooting

    If further minutes, and then plug it back in. assistance is needed, go to my.iFIT.com, scan c. Remove the key from the console, and then the QR code at the right, reinsert it.
  • Page 26 SYMPTOM: The incline of the treadmill does not SYMPTOM: The walking belt is off-center change correctly a. First, remove the key and UNPLUG THE POWER a. See HOW TO CHANGE CONSOLE SETTINGS on CORD. If the walking belt has shifted to the left, page 21 to calibrate the incline system.

  • Page 27: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.

  • Page 28: Part List

    PART LIST Model No. PFTL90924.1 R0723A Key No. Qty. Description Key No. Qty. Description Key/Clip Drive Roller/Pulley 5/16" x 3/4" Screw Frame 5/16" Bushing Right Rear Foot 3/8" x 2 3/8" Screw Left Rear Foot 3/8" Star Washer Idler Roller 5/16"...

  • Page 29: Exploded Drawing

    EXPLODED DRAWING A Model No. PFTL90924.1 R0723A...
  • Page 30 EXPLODED DRAWING B Model No. PFTL90924.1 R0723A...
  • Page 31 EXPLODED DRAWING C Model No. PFTL90924.1 R0723A...

  • Page 32: Ordering Replacement Parts

    This warranty extends only to the original purchaser (customer) and is not transferrable. iFIT’s obligation under this warranty is limited to repairing or replacing, at iFIT’s discretion, the product through one of its authorized service providers. All repairs for which warranty claims are made must be preauthorized by iFIT.
