proform.com

Model No. PFTL38824.0

Serial No.

Write the serial number in the space

above for reference.

Serial

Number

Decal

PRODUCT

To register your product and

activate your warranty today,

go to my.proform.com.

MEMBER CARE

For service at any time, go to

my.iFIT.com or scan the QR code.

Please do not contact the store.

CAUTION

Read all precautions and

instructions in this manual before

using this equipment. Keep this

manual for future reference.

USER'S MANUAL

Need help?

Do you have a question about the PRO-FORM CADENCE 4.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for iFIT PRO-FORM CADENCE 4.0

Page 1 To register your product and activate your warranty today, go to my.proform.com. MEMBER CARE For service at any time, go to my.iFIT.com or scan the QR code. Please do not contact the store. CAUTION Read all precautions and instructions in this manual before using this equipment.
Page 2 Note: The decal(s) may not be shown at actual size. PROFORM and IFIT are registered trademarks of iFIT Inc. App store is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks of Google LLC. The Bluetooth word mark ®...
Page 3 To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on the treadmill before using the treadmill. iFIT assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
Page 4 19. Read, understand, and test the emergency 26. When folding or moving the treadmill, make stop procedure before using the treadmill sure that the storage latch is holding the (see HOW TO TURN ON THE CONSOLE on frame securely in the storage position. Do page 14).
Page 6 BEFORE YOU BEGIN Thank you for selecting the new PROFORM reading this manual, please see the front cover of this ® CADENCE 4.0 treadmill. The CADENCE 4.0 treadmill manual. To help us assist you, note the product model offers a selection of features designed to make your number and serial number before contacting us.
Page 7 PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
Page 8 ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •...
Page 9 2. Make sure that the power cord is unplugged. Carefully raise the Upright (56) to the vertical position. Next, start an M10 x 45mm Screw (1) and an M10 x 20mm Screw (2) into the Upright (56) and the Base (63) as shown; then, tighten both Screws.
Page 10 4. Orient the Storage Latch (55) as shown. Attach the Storage Latch to the left side of the Upright (56) with two #10 x 1" Tek Screws (67). 5. Set the console assembly (A) on the Left and Right Handrails (49, 50). Attach the console assembly (A) with four M4 x 19mm Screws (68);...
Page 11 Console (52). Note: If you do not have a smartphone or tablet, use your computer to go to iFIT.com/activate for an alternate way to activate the Console (52). If you do not have a computer, contact Member Care (see TROUBLESHOOTING on page 22).
Page 12 HOW TO PLUG IN THE POWER CORD USE A SURGE SUPPRESSOR overloading the circuit, do not plug other electrical devices, except for low-power devices such as cell Your treadmill, like other electronic equipment, can be phone chargers, into the surge suppressor or into damaged by sudden voltage changes in your home’s an outlet on the same circuit.
Page 13 To turn on and turn off the console, see page 14. To a touch of a button. As you exercise, the console will use the manual mode, see page 15. To use an iFIT display continuous exercise feedback. workout, see page 16. To change console settings, see page 18.
Page 14 HOW TO TURN ON THE CONSOLE IMPORTANT: The console may feature a demo mode, designed to be used if the treadmill is dis- ETPF38824 IMPORTANT: If the treadmill has been exposed to played in a store. If the display lights as soon as cold temperatures, allow it to warm to room tem- you plug in the power cord and press the power perature before you turn on the console.
Page 15 Calories per Hour (CALS/HR)—The approximate HOW TO USE THE MANUAL MODE number of calories you are burning per hour. 1. Insert the key into the console. Time—The elapsed time. See HOW TO TURN ON THE CONSOLE on page 14. Pace—The speed in minutes per mile or minutes per kilometer.
Page 16 App Store℠ or the Google Play™ store, search for indicator will turn the free iFIT app, and then install the app on your on in the display. When workout information is smart device. Make sure that the Bluetooth option removed, its indicator will turn off.
Page 17 In addition, if you manually change the In the iFIT app, touch the buttons at the bottom of speed during the workout, the number of calo- the screen to select either the home screen (Home ries you burn will be affected.
Page 18 Demo Mode—The currently selected demo mode HOW TO CHANGE CONSOLE SETTINGS option will appear in the display. The console features a demo mode, designed to be used if the 1. Select the settings mode. treadmill is displayed in a store. If the demo mode To select the settings mode, is turned on, the console will not turn off and the press the settings button (H).
Page 19 To connect your Bluetooth Smart heart rate moni- tor to the console, press the iFIT Sync button on the console; the console pairing number will appear in the display. When your heart rate monitor is connected, the LED on the console will flash red twice.
Page 20 FCC INFORMATION This console has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 21 HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL Before moving the treadmill, fold it as described at Before folding the treadmill, remove the key and the left. CAUTION: Make sure that the frame (C) is unplug the power cord.
Page 22 For further assistance, minutes, and then plug it back in. go to my.iFIT.com, scan the QR code at the right, c. Remove the key from the console, and then or call 1-833-680-IFIT reinsert it.
Page 23 SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is off-center a. Use only a surge suppressor that meets all of the a. First, remove the key and UNPLUG THE POWER specifications described on page 12. CORD. If the walking belt has shifted to the left, use the hex key to turn the left idler roller screw b.
Page 24 EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.
Page 25 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
Page 26 NOTES...
Page 27 NOTES...
Page 28 PART LIST Model No. PFTL38824.0 R0823A Key No. Qty. Description Key No. Qty. Description M10 x 45mm Screw Controller M10 x 20mm Screw Electronics Bracket M10 x 55mm Screw Cable Tie #8 x 3/4" Screw Frame M10 Star Washer Right Rear Foot M10 x 85mm Screw Left Rear Foot M8 x 80mm Screw...
Page 29 EXPLODED DRAWING A Model No. PFTL38824.0 R0823A...
Page 30 EXPLODED DRAWING B Model No. PFTL38824.0 R0823A...
Page 31 EXPLODED DRAWING C Model No. PFTL38824.0 R0823A...
Page 32 This warranty extends only to the original purchaser (customer) and is not transferrable. iFIT’s obligation under this warranty is limited to repairing or replacing, at iFIT’s discretion, the product through one of its authorized service providers. All repairs for which warranty claims are made must be preauthorized by iFIT.
