Summary of Contents for Thermo Scientific Compact Digital MicroPlate Shaker
- Page 1 Compact Digital MicroPlate Shaker Orbital Motion, 100-240V AC, 50/60Hz Operation Manual 9240-11-017...
- Page 2 No such use, or the use of any trade name, is intended to convey endorsement or other affiliation with Thermo Fisher Scientific. ©2013 Thermo Fisher Scientific. All rights reserved. MANUAL NUMBER 9240-11-017 12/5/13 Original ECR/ECN DATE DESCRIPTION Thermo Scientific MicroPlate Shaker...
- Page 3 3) The claim which is out of the quality guarantee published by the Manufacturer is out of Manufacturer’s responsibility. 4) The damage which is from unexpected fault or damage of user by Acts of God is out of Manufacturer’s responsibility. MicroPlate Shaker Thermo Scientific...
- Page 4 We can also provide you with a quotation on our Extended Warranty for your Thermo Scientific products. Whatever Thermo Scientific products you need or use, we will be happy to discuss your applications. If you are experiencing technical problems, working together, we will help you locate the problem and, chances are, correct it yourself...over the telephone without a service...
-
Page 5: Table Of Contents
Warranty Information ..........9-1 Thermo Scientific... -
Page 6: Warnings And Cautions
Do not use the machine at places where moisture is high and flooding can be happened. Do not assemble, repair, modify on your own. The product may not work well and electric shock change the efficiency of the product. Also this will void the warranty. Thermo Scientific MicroPlate Shaker... - Page 7 Power off while product cleaning. It may cause the electric shock or fire. Disconnect the power plug if some sounds and burning smell, smokes occur. And request service. Do not let the product take shock by falling down. It will cause wrong operation and malfunction. MicroPlate Shaker Thermo Scientific...
-
Page 8: Section 2 Functional Descriptions
Functional Descriptions Section 2 Compact Digital MicroPlate Shaker can be operating large amount of sample (4 Microplates in same time). And the shaker is designed for conveniences and safety of the experiment. Features Performance • Rotation diameter 3mm, 150 ~ 1,200 rpm rotational speed with stable rotation speed can be selected to user suitable purpose. -
Page 9: Construction
(6) Dial knob : to set a shaking speed / Timer and start / stop. (7) Fixing Rubber: to be placed Microplate on the plate. (8) Foot: to prevent from slippery and support main body (9) Socket: Connect the power cable on the socket. MicroPlate Shaker Thermo Scientific... -
Page 10: Installation
Checking Instrument Check the instrument components supplied in the package after unpacking. If a noticeable issue or an omission is found, immediately Components notify your local Thermo Scientific dealer’s Service Department. BASIC COMPONENT QUANTITY/ RECEIVED DESCRIPTION Operating Manual... -
Page 11: Connecting To The Mains Power Supply
Operate after inserting four Microplates for balancing. If you insert two Microplates, install them diagonally. Likewise, when you remove the plate, push the outside home of the plate tray to the direction of the fixing rubber. Lift and remove it. MicroPlate Shaker Thermo Scientific... -
Page 12: Operation
During operation, if you push it, you can check how long it has operated and during stop, if you push it, you can set timer. (4) Dial knob : RPM setting, Input time, or stop the unit Thermo Scientific MicroPlate Shaker... -
Page 13: Start And Stop
STEP 2: Press dial knob 1 time. STEP 3: Input minute by rotating dial knob to right Push button & or left direction. turn right STEP 4: Press dial knob 1 time. Display moves to next mode (RPM setting) MicroPlate Shaker Thermo Scientific... -
Page 14: Stop Timer
• Timer Mode can be cancelled in any step if the Timer button is pressed to get back to standby mode. If the Timer button is pressed again, time or rpm can be set. • Timer Mode can be stopped as indicated above. Thermo Scientific MicroPlate Shaker... -
Page 15: Safety Device For Overload
• Do not put too much sample in the tray for preventing by contamination each samples. Safety Device for Performance of motor does not work well with an overload. Internal safety circuit stops operation with an alarm. The unit operates fine after re- Overload booting. MicroPlate Shaker Thermo Scientific... -
Page 16: Maintenance
Keep the unit cleans always without any contaminant. • Do not soak the product in the water to clean. Keeping Product Unplug the instrument from the main power. Clean the instrument with a soft cloth neatly. Store in a dry place after packing. Thermo Scientific MicroPlate Shaker... -
Page 17: Troubleshooting
No VFD Inner circuit defect Request service. Pull out the button to check connector and than retry operating. Button doesn’t work Button switch has damage Otherwise, request service. Thermo Scientific MicroPlate Shaker... - Page 18 Inner rotating support defect Request service. Set proper max. load value to limit Motor stops by over pressure overload safety device. Re-boot for normal operation Operating suddenly stops BLDC motor and circuit defect Request service. MicroPlate Shaker Thermo Scientific...
-
Page 19: Accessories
Tube support 50ml 88880116 Tube support (50ml) Tube Support 1.5ml Attach two racks on the plate. For balanced fit, micro-tubes should be attached to the racks with bilateral symmetry. Use the cap to prevent micro-tube’s break away. Thermo Scientific MicroPlate Shaker... -
Page 20: Tube Support 50Ml
Attach two racks on the plate. For balanced fit, conical tubes should be attached to the racks with bilateral symmetry. Tube Support 50ml Attach two racks on the plate. For balanced fit, conical tubes should be attached to the racks with bilateral symmetry. Magnetic Stirrer Thermo Scientific... -
Page 21: Technical Specifications
Technical Specifications Section 8 Item / Model Compact Digital MicroPlate Shaker Speed range (rpm) 150~ 1,200 Speed control type Feedback Control PID Shaking System Orbital diameter 3 / 0.12 (mm/inch, dia) Timer 1min to 99 hr 59 min Safety device Over current protection Max. -
Page 22: Disposing Of The Product
(2) If not possible, contact your local governing body for regulations regarding disposal of laboratory equipments. Thermoi Scientific highly recommends you to find a local service provider that can properly dispose of your instrument. Magnetic Stirrer Thermo Scientific... -
Page 23: Warranty Information
REGISTERED Rev. 0 9/13 For the name of the authorized Thermo Scientific product dealer nearest you or any additional information, contact us: North America: USA/Canada +1 866 984 3766 (866-9-Thermo) www.thermo.com Europe: Austria +43 1 801 40 0, Belgium +32 2 482 30 30, France +33 2 2803 2180, Germany national toll free 08001-... - Page 24 Thermo Fisher Scientific 401 Millcreek Road Marietta, Ohio 45750 United States www.thermofisher.com...
