- Page 1 Magnetic Stirrer BIOSYSTEM DIRECT BIOSYSTEM Operating Manual 50134801 Issue 03.2012 Directly and remote-controlled single and multiple magnetic stirring systems...
- Page 2 Thermo Electron LED GmbH Robert-Bosch-Straße 1 D-63505 Langenselbold Germany national toll free: Phone Sales: 0800 1536376 Phone Service 0800 1112110 Fax: 0800 1112114 Germany international: Phone: +49 6184 906940 Fax: +49 6184 906772 E-mail: info.labequipment.de@thermofisher.com For further help see: www.thermofisher.com Thermo Scientific 50134805_03.2012...
-
Page 3: Table Of Contents
Function ...................11 Startup procedure ..............12 Stirring operation..............14 6.1 Stirring vessels ..............14 6.2 Magnetic stirring bars ............15 6.3 Recommended rotation speed ranges ......18 6.4 Stirring ................18 Maintenance and cleaning ............21 Troubleshooting ...............22 Accessories ................24 Technical Specifications ............25 Warranty ..................28 50134805_03.2012 Thermo Scientific... - Page 4 Figure 1: Single magnetic stirring system BIOSYSTEM 1 with plug-in power supply unit. *) Not included in scope of delivery. stirring device* stirring vessel* magnetic stirrer control cable power cable control unit Figure 2: Multiple magnetic stirring system BIOSYSTEM 4 B with control unit BIOMODUL 40 B. Thermo Scientific 50134805_03.2012...
- Page 5 16 Stirring power control button 17 rotation speed control button 18 power ON/OFF switch 19 power input 20 Output socket Figure 3: Control unit BIOMODUL 40 B, front view Figure 4: Control unit BIOMODUL 40 B, back view 50134805_03.2012 Thermo Scientific...
-
Page 6: User Considerations
This sign refers to dangerous voltages. DANGER! This sign refers to hazardous situations. CAUTION! This sign indicates danger to equipment and machinery. INFORMATION This sign indicates easier working practices. Indicates an operating step. Indicates alternatives. Thermo Scientific 50134805_03.2012... -
Page 7: Safety Considerations
The vortex should not reach the stirring bar. The stirring bar must rotate in the center of the sample vessel. Watch the rotational behavior of the mixing stick for slow starts CAUTION! The equipment must not be operated in hazardous locations. 50134805_03.2012 Thermo Scientific... - Page 8 CAUTION! Do not use cleaning agents which attack and corrode the stainless steel surface of the magnetic stirrer (5). CAUTION! In case of repair, the equipment must only be opened by an authorised service agent. Thermo Scientific 50134805_03.2012...
- Page 9 INFORMATION Read the instructions carefully before using the magnetic stirrer. No application of the device by an untrained and inexperienced personnel. INFORMATION Use only in the instructions specified accessories, according to the illustrated configuration. 50134805_03.2012 Thermo Scientific...
-
Page 10: Equipment Description
(5). The magnetic stirrer (5) is cleared for use in safety laboratories and sterile rooms. Stirring vessel (2) and stirring device (1) do not fall within the scope of delivery. Thermo Scientific 50134805_03.2012... -
Page 11: Function
To stop and restart the stirring device (1), the control unit (9) is fitted with a start/stop key (13). The rotation speed is slowly reduced, and then slowly increased again. 50134805_03.2012 Thermo Scientific... -
Page 12: Startup Procedure
The magnetic stirring system must be switched off before connecting or pulling the connector. BIOSYSTEM DIRECT: The rotation speed control button (6) must always be brought to position OFF first. BIOSYSTEM: Switch off control unit (9) using power ON/OFF switch (18). Thermo Scientific 50134805_03.2012... - Page 13 Connect the power cable (8) to the power input (19) on the control unit (9) and into the mains socket. If a germ-free environment is required, accommodate the control unit (9) outside the sterile area. 50134805_03.2012 Thermo Scientific...
-
Page 14: Stirring Operation
(e.g. by using a spacer under the stirring vessel), the radius of the pendulum motion will be reduced (Figure 5, right). Keep changing the distance between the stirring vessel (2) and the magnetic stirrer (5) until you achieve an optimum pendulum motion. Thermo Scientific 50134805_03.2012... -
Page 15: Magnetic Stirring Bars
(Figure 3). Any risk of demagnetization by external magnetic fields is completely eliminated. All KOMET series stirring bars can be readily recognized by their two conical ends. 50134805_03.2012 Thermo Scientific... - Page 16 (Figure 4). Alternatively, it can be fixed at the bottom of the stirring vessel with the aid of a centering device (centering device not included in scope of delivery). Thermo Scientific 50134805_03.2012...
- Page 17 The latter prevents the magnetic stirring bar from escaping in a sideways direction. When using the stirring disc, take care to note that it will not rotate of its own accord. Affix it to the bottom of the vessel, for example. Figure 5: Stirring disc with screen 50134805_03.2012 Thermo Scientific...
-
Page 18: Recommended Rotation Speed Ranges
The stirring bar must rotate in the center of the sample vessel. Watch the rotational behavior of the mixing stick for slow starts CAUTION High speed rotations of the stirring bar can cause a warming of the goods. Thermo Scientific 50134805_03.2012... - Page 19 If you want to reverse the direction of rotation, lock the rotation direction key (15) to position STIR. The yellow LED display in the rotation direction key (15) will light up. 50134805_03.2012 Thermo Scientific...
- Page 20 Release the start/stop key (13). The rotation speed will be slowly increased to the preselected rotation speed. If you want to terminate the stirring process: Switch off the control unit (9) using the power ON/OFF switch (18). Thermo Scientific 50134805_03.2012...
-
Page 21: Maintenance And Cleaning
In case of ordering spares, please state equipment type and serial number. You can obtain further technical documents (e.g. circuit diagrams, board data) for your engineers by contacting the address on the inside of the cover sheet. 50134805_03.2012 Thermo Scientific... -
Page 22: Troubleshooting
Check to see whether the stirring device (1) comes into contact with the base of the vessel (Figure 6d). If this is the case, raise and fix the stirring device (1) at a higher point. Magnet coupling Ø 60 mm = Magnetic field lines Figure 6: Positioning of stirring device. Thermo Scientific 50134805_03.2012... - Page 23 Place a thermal insulating shield between the stirring vessel (2) and the standing surface of the magnetic stirrer (5). BIOSYSTEM: reduce the stirring power as far as possible using the stirring power control button (16). 50134805_03.2012 Thermo Scientific...
-
Page 24: Accessories
Immersible thermostat (Order No. 50087867) According to DIN 12879, Safety Class 0. Adjustable temperature range +25° to +95°C, temp. fluctuation 0.3°C, Variable excess temperature fuse (temperature monitor), heat output 1.5 kW. Mains connection 115 V/ 50-60 Hz. Thermo Scientific 50134805_03.2012... -
Page 25: Technical Specifications
Power supply: +10 to +40 at max. 80% humidity temperature Operating voltage Protection* IP 66 Immersible thermostat, Connecting cable, Accessories Culture vessels The jack located at the back of the magnetic stirrer (5) is not protected. Subject to technical alterations 50134805_03.2012 Thermo Scientific... - Page 26 +10 °C to +40 °C at 30 % to 75 % relative humidity operating conditions 700 to 1060 hPa barometric pressure Permissible -40 °C to +70 °C, at max. 80 % relative humidity, storage conditions 500 to 1060 hPa barometric pressure Subject to technical alterations Thermo Scientific 50134805_03.2012...
- Page 27 +10 °C to +40 °C at 30 % to 75 % relative humidity operating conditions 700 to 1060 hPa barometric pressure Permissible -40 °C to +70 °C, at max.80 % relative humidity, storage conditions 500 to 1060 hPa barometric pressure Subject to technical alterations 50134805_03.2012 Thermo Scientific...
-
Page 28: Warranty
If despite our strict quality controls a system component should ever fail to work perfectly, it can be repaired or replaced by our after-sales service with no difficulty. Please retain your invoice, which will be needed when presenting any warranty claims. Thermo Scientific 50134805_03.2012...
