7

Board connectors

Several connectors are implemented on the B-WL5M-SUBG1 product:
• Five connectors are implemented on the MB1779 expansion board.
• Three connectors are implemented on the MB1880 fan-out board.
7.1

MB1779 STMod+ (CN1)

CN1 is an STMod+ connector (male). This connector allows interfacing the MB1779 board to:
• A host board (having an STMod+ female connector), so that the MB1779 is acting as an expansion board,
• An MB1880 STMod+ adapter board, so that the B-WL5M-SUBG1 product formed by the couple MB1779/
MB1880 is acting as a host board.
The related pinout for the STMod+ connector is listed in
Pin number
1
2
3
4
5
6
7
8
9
10
UM3127 - Rev 1
Figure 31. STMod+ connector (CN1)
Table
Table 14. STMod+ connector (CN1) pinout
STM32 pin (1)
PA4
or
PB12
PA7
or
PC0
PA6
or
PC1
PA5
or
PA6
-
-
PA12
PB5
PB4
PA11
14.
Function (1)
SPI1_NSS (if SB3 is ON)
or
UART1_RTS (if SB1 ON)
SPI1_MOSIP (if SB6 is ON)
or
UART1_RX (if SB4 ON)
SPI1_ MISOP (if SB18 is ON)
or
UART1_TX (if SB16 ON)
SPI1_SCK (if SB22 is ON)
or
UART1_CTS (if SB19 ON)
GND
5 V supply
I2C2_SCL
SPI1_MOSIS
SPI1_MISOS
I2C2_SDA
UM3127
Board connectors
