6.3.2

Power via the STMod+ adapter board (MB1880) supplied through a USB Type-C

The CEB MB1779 board can be powered by 5V coming from the USB Type-C
board (MB1880). This USB Type-C
• A PC through a USB cable
• A USB charger
This is displayed in
Figure 12.
Input power name
6.3.3

Power via STMod+ adapter board (MB1880) supplied through a host

The CEB MB1779 board can be powered by 5V coming from the second STMod+ connector of the STMod+
adapter board (MB1880). This STMod+ connector can be connected to a host.
This is displayed in
Figure 13.
Host
UM3127 - Rev 1
®
connector can be connected to:
Table 6 and Figure 12.
Power supply input from 5V via the STMod+ adapter board (MB1880) connected to a PC
PC / USB charger
Table 6.
Connector pins
5V MB1880 - CN1
Figure 13.
Power supply input from 5V via STMod+ adapter board (MB1880) connected to a host
through a USB connector
External power source 5V (5 V)
Voltage range
5 V
UM3127
Hardware layout and configuration
®

connector

®
connector of the STMod+ adapter
Maximum current
500 mA
page 13/47
