- Page 3 Important Safety Instructions Please save these instructions. This manual contains important safety, installation, and operating instructions for the charge controller. The following symbols are used throughout the manual to indicate potentially dangerous conditions or important safety information. ◼ General Safety Information ⚫...
- Page 4 ⚫ Do NOT let the positive (+) and negative (-) terminals of the battery touch each other. Recycle battery when it is replaced. ⚫ Over-charging and excessive gas precipitation may damage the battery plates and activate material shedding on them. Too high of an equalizing charge or too long of one may cause damage.
-
Page 5: Table Of Contents
Warranty ............................1 General Safety Information and waiver liability ................1 Overview ............................2 Dimensions ............................3 Installtion ............................3 Operation ............................6 Troubleshooting and protections ....................8 Technical Date ..........................9 Content Included ........................... 10... -
Page 6: Warranty
Warranty Dear Customers, Thanks for choosing the MPPT series solar charge controller. Please take time to read this user manual carefully, it will help you to make full use of many advantages the controller can provide your solar system. This manual gives important recommendations for installing and using and so on. Read it carefully in your own interest and pay attention to the safety recommendations in it please. -
Page 7: Overview
5) Red wire connected positive Pole of controller and black wire connected positive Pole of controller 6) Contact us first if you have any questions. ◼ Liability Disclaimer The manufacture shall not be liable for damages, especially on the battery, caused by use other than as intended or as mentioned in this manual or if the recommendations of the battery manufacturer are neglected. -
Page 8: Dimensions
Dimensions Notes: Please use our screws only since it damaged the internal PCB if using other screws. Please yes proper torque to push the screws into casing since it may damaged the internal PCB by strong torque Installation ◼ Instruction Notes step: Connect the batteries Connect the battery connection cable with the correct polarity to the middle pair of terminals on the solar charge controller(with the battery symbol).if the system is... - Page 9 Connections must always be made in the sequence described below. Air Circuit Breaker and Wires Requirement Models Copper wires Air circuit breakers MPPT-60A 6mm² x2PCS 100A...
- Page 10 Remnder It’s better to connect two wires to two PV+ and another two wires to two PV-. For BAT+ and BAT-, it’s same way to connect wires. MPPT SOLAR CHARGE CONTROLLER Circuit breaker Circuit breaker DC Load Battery 1. Install air circuit breaker between controller and batteries. Turn off the circuit breaker, then connect batteries to controller with correct polarity.
-
Page 11: Operation
Operation LCD display Item Description PV voltage / Output power Battery voltage / Charging current Working mode / Temperature Protection mode Working mode 3. 0 Night mode, no charging 4. 0 MPPT mode 7. 0 Absorption mode 8. 0 Floating mode... - Page 12 Batteries charge voltage reference Battery Type Absorption Voltage ( Constant Floating Voltage voltage ) Vented 14.2V 28.6V 57.2V 13.2V 26.4V 52.80V Sealed 14.4V 28.8V 57.6V 13.8V 27.6V 55.2V 14.4 V 28.8V 57.6V 13.8V 27.6V 55.2V NiCd 14.2V 28.6V 57.2V 14.0V 28.0V 56.0V Lithium or others...
-
Page 13: Troubleshooting And Protections
series, the controller will multiply them in proportion automatically and the LCD only displays the voltage of one battery. Step 4: D03 Continue to press the button UP, LCD shows 10.0. This is protection value of battery discharge. Press ENT until numbers flash, then press UP/DOWN to set up voltage that you want, long-press ENT to confirm it. -
Page 14: Technical Date
⑦ Load Short Circuit Protection Once the load short circuit happens, the Load Short circuit protection will start automatically. ⑧ Over Temperature Protection Technical Date Models MPPT-60A 3-stage: constant current(MPPT), Charging mode 4-constant voltage, Floating Max.PV Input Power 12V system... -
Page 15: Content Included
48V system DC 72V~160V Battery voltage automatic recognition: 12V DC9V~DC15V Battery Battery voltage automatic recognition: 24V DC18V~DC29V Battery Battery voltage automatic recognition: 36V DC30V~DC39V Battery Battery voltage automatic recognition: 48V DC40V~DC60V Battery Overcharging protection voltage Limited current protection ≥98. 1% Max efficiency ≥99% PV utilization...
