Ispring RCC7AK User Manual page 5

Parts Index
0. O-ring seated on top of housing
1. 1st stage transparent housing
2. 2nd stage housing
3. 3rd stage housing
4. 1st stage sediment cartridge
5. 2nd stage GAC cartridge
6. 3rd stage CTO cartridge
7. 4th stage RO membrane housing cap
8. 5th stage Post carbon T33
9. 6th stage Alkaline (optional)
10. RED tubing inlet
11. YELLOW tubing inlet
12. BLUE tubing or ice maker T-fitting inlet 24. Ice maker kit (optional)
13. To Cold Water Supply Flex Tube
www.123filter.com | (678) 261-7611
14. To Cold Water Supply Valve
15. Drain saddle
16. Drain saddle sticky pad
17. RO faucet front plate
18. RO faucet back washer
19. Big housing wrench
19a. Membrane housing wrench
20. Tank seat
21. Tank fitting
21a. Tank Shut-off Valve (open)
22. Housing cap with center knob
23. Rubber washer
sales@ispringfilter.com | Rev 03/14 | p5/10
