Danfoss DEVIreg Room 140F1161 Installation Manual page 22

22
INSTALLATION GUIDE
DEVIreg™ Room
Schedule
Default settings and out of the box settings.
The DEVIreg™ Room will have the following settings out of the box:
Maximum Room temperature 35 °C
Maximum oor temperature: 28 °C
Minimum oor temperature 5 °C
If the thermostat is placed onto the schedule (clock) icon without having
the app connected, the temperature is default 21 °C
• This indicator lights up white when the built
in schedule changes from Non active to
active and vice versa. After some seconds, the
indicator fades out.
• The indicator ashes in part of the paring
process.
• This indicator ashes white when there are
warnings. The warning will be present until
App communication is activated, however the
indicator will only ash for a duration (default
20 seconds). Warnings will be displayed in
the App.
