Summary of Contents for Danfoss DEVI DEVIreg 330
- Page 1 Installation Guide DEVIreg™ 330 (+60 °С to +160 °C) Electronic Thermostat www.DEVI.com...
-
Page 3: Table Of Contents
DEVIreg™ 330 (+60 °C to +160 °C) Table of Contents Introduction ....... . . 3 Technical Specifications . -
Page 4: Technical Specifications
DEVIreg™ 330 (+60 °C to +160 °C) Technical Specifications Operation voltage 220-240 V~, 50-60 Hz Standby power consumption Max 0,25 W Relay: Resistive load Max 16 A / 3680 W @ 230 V Inductive load cos φ= 0,3 max1A Sensing units NTC 16,7 kOhm at 100 °C Sensing values: 25 °C... -
Page 5: Safety Instructions
DEVIreg™ 330 (+60 °C to +160 °C) IP class Protection class Class II Dimensions 86 x 36 x 58 mm Weight 83 g The product complies with the EN/IEC Standard “Automatic electrical controls for household and similar use”: • EN/IEC 60730-1 (general) •... -
Page 6: Mounting Instructions
DEVIreg™ 330 (+60 °C to +160 °C) • If temperature wire sensor is applied on conductive surface it must be installed with additional electrical insulation. • Caution: temperature sensor, heated surface and heat- ing cable could have really high temperature. •... - Page 7 DEVIreg™ 330 (+60 °C to +160 °C) Sensor 250V~ Mains 16 (1) A 220-240V~ Max. 10 A (cooling) Load max. 16 A (heating) The screen of the heating cable must be connected to the earth conductor of the power supply cable by using a separate connector.
-
Page 8: Warranty
DEVIreg™ 330 (+60 °C to +160 °C) Warranty Disposal Instruction Installation Guide... - Page 9 DEVIreg™ 330 (+60 °C to +160 °C) Installation Guide...
- Page 10 DEVIreg™ 330 (+60 °C to +160 °C) Installation Guide...
- Page 11 DEVIreg™ 330 (+60 to +160°C) Danfoss A/S Nordborgvej 81 6430 Nordborg, Syddanmark Denmark 08091318 & AQ087886468701en-000302 Produced by Danfoss © 06/2020...
