INSTALLATION GUIDE
DEVIreg™ Room
Description
3. The bending radius for the
Flexpipe must be more than
50 mm.
4. Make sure the oor sensor is
located with equal distances
between two heating
cables (> 2 cm) located at a
representative position.
5. For thin oor constructions:
the Flexpipe should be ush
with the sub- oor surface,
countersink the Flexpipe if
possible.
For thicker constructions: the
Flexpipe including the sensor
should be located such that
the sensor is exposed to a
representative heating level,
our recommendation is still
that the sensor must be located
equidistant between the cables
or mat runs.
Illustration
1
≥
2
