SC&T IP09CP User Manual page 5

Advanced Mode
Please refer to the chart below to manually set up the Link Speed, and Modes
NO Function
1 Link Speed
2 Ethernet
3 100BASE-T1
4 Long Distance
Auto-Negotiation Priority
Priority
1
(Highest)
2
3
4
5
6
7
(Lowest)
Power and Transmission Distance
The reports below show the extension distance and the amount of power transferred by distance.
All statistics are from the result of using 24AWG CAT5e, 75Ω RG59/RG6U coaxial cables to test.
Transmission distance & data rate by different modes

Mode
100BASE-TX with EEE
100BASE-TX
100BASE-T1
Long Distance
10BASE-T with EEE
10BASE-T
Long Distance
Transmission distance by different BNC connectors & data rate

Cable Data Rate
RG59 (75-3) 100Mbps
RG6U (75-5) 100Mbps
RG59 (75-3) 10Mbps
RG6U (75-5) 10Mbps
↑ OFF
10Mbps
Disable
Disable
Disable
Mode
Long Distance 100Mbps
100BASE-T1
Long Distance 10Mbps
100BASE-TX Full Duplex
100BASE-TX Half Duplex
10BASE-T Full Duplex
10BASE-T Half Duplex
Data Rate Distance
100Mbps 100M
100Mbps 130M
100Mbps 300M
100Mbps 500M
10Mbps 100M
10Mbps 250M
10Mbps 800M
Distance
500M
500M
800M
800M
↓ ON
100Mbps
Enable
Enable
Enable
User Manual
IP09CP
4
