F&F PCS-516 UNI Quick Start Manual page 6

When the power supply of the relay is switched on, the
system does not react to the change of time range and
working time settings.
Operation with the newly set time range and operating
mode takes place after the power supply is switched off
and back on.
With the power supply switched on, it is possible to
smoothly adjust the time within the time range of 1÷12.
Time ranges
0,1 s:
1 s:
10 s:
1 m:
ON
OFF
Mounting
1. Turn off the power supply.
2. Fix the relay on a rail in the switchboard.
3. Connect the power supply wires to terminals 1-3.
4. Connect the power supply circuit of the receiver in series to
terminals 11-12.
0.1÷1.2 sec
1÷12 sec
10÷120 sec
1÷12 min.
when the power supply is on, the contact is perma-
nently closed in position 11-12.
when the power supply is on, the contact is perma-
nently closed in position 11-10.
10 m: 10÷120 min.
2 h: 2÷24 hours
1 d: 1÷12 days (24÷288 h)
2 d:
2÷24 days (48÷576 h)
- 6 -
