Supplemental Installation Manual
IMPORTANT NOTES:
•
All installs are to be done by a journeymen electrician. If an apprentice is helping it is the journeyman's
responsibility to ensure all work is to building standards.
•
A lockable disconnect is required in a readily accessible location (CEC 625.42) for EV charging
stations > 60A or 150V to ground. The disconnect does not have to be fusible but must comply with
NEC regulations.
Advertisement
Related Manuals for Ford PRO
Summary of Contents for Ford PRO
- Page 1 Supplemental Installation Manual IMPORTANT NOTES: • All installs are to be done by a journeymen electrician. If an apprentice is helping it is the journeyman’s responsibility to ensure all work is to building standards. • A lockable disconnect is required in a readily accessible location (CEC 625.42) for EV charging stations >...
- Page 2 In addition to the standard installation tools, you will be required to have a have a Hand Crimping Tool (Greenlee brand shown below or comparable), an Inch Pound Torque Screwdriver and a 6mm Tapping Tool. Before you begin your install make sure when unpackaging the unit that all equipment is on hand and has not been damage.
- Page 3 Its important to note that regardless of a rear conductor entry or from the bottom the following steps be followed. Pre- bend conductors so they align with the appropriate terminals on the unit. This should be done prior to installing any high press lugs.
