NTI UNIMUX SERIES HD4K 18GB VIDEO USB KVM SWITCH
I NTRODUCTION
0 B 0 B
The UNIMUX™ 4K 18Gbps HDMI USB KVM Switch allows a user to control up to 32HDMI 2.0 Ultra-HD 4Kx2K 60Hz 4:4:4 USB
computers with one USB keyboard, USB mouse, and 4K HDMI monitor. Dedicated internal microprocessors emulate keyboard
and mouse presence to each attached CPU 100% of the time so all computers boot error-free.

Supports Ultra-HD 4Kx2K resolutions to 3840x2160 and 4096x2160 @24/30/60Hz RGB/YUV 4:4:4, HDTV resolutions to
1080p @120Hz, and up to 1920x1200 (WUXGA).

HDMI features supported:
HDMI 2.0
o
Up to 12-bit Deep Color on input and 8-bit on output.
o
Dolby TrueHD, DTS-HD Master Audio, Dolby Digital, Dolby Digital+, Dolby Atmos, LPCM 2/5.1/7.1CH, DTS 5.1,
o
and DTS:X
RGB, YUV 4:4:4, YUV 4:2:2, and YUV 4:2:0
o
Bandwidth up to 600 MHz (18Gbps)
o
3D (1080p @60Hz)
o
HDR
o

HDCP 2.2 compliant.
 Features NTI's patented true autoboot USB switching – all attached computers can be booted simultaneously.

Compatible with USB computers (PC and MAC) with HDMI outputs.

Control the switch through the front panel buttons, keyboard commands, OSD, or RS232.

Two transparent USB 2.0 ports, in addition to keyboard and mouse ports, for connecting USB devices such as printers,
game controllers, USB flash drives, touch screen monitors, whiteboards, etc.
Supports high-speed (480 Mbps), full speed (12 Mbps), or low speed (1.5 Mbps) USB devices.
o

Supports Plug-n-Play specification.

High quality steel construction.

Flash upgradeable.

Rackmount kit included.

Cable management tray included.
