G2962, G2994
Manual-tilt Bratt Pans
INSTALLATION and SERVICING
INSTRUCTIONS
These appliances must be installed and serviced by a qualified person as stipulated by the Gas Safety (Installation &
Use) Regulations.
IMPORTANT
The installer must ensure that the installation of the appliance is in conformity with these instructions and National Regulations
in force at the time of installation. Particular attention MUST be paid to -
I.E.E Regulations for Electrical Installations
Electricity At Work Regulations
Gas Safety (Installation & Use) Regulations
Health And Safety At Work etc. Act
Local and National Building Regulations
These appliances have been UKCA/CE-marked based on compliance with the Gas Appliance Regulations/ Product Safety and
Metrology Regulations for the Countries, Gas Types and Pressures as stated on the data plate.
WARNING - TO PREVENT SHOCKS, ALL APPLIANCES WHETHER GAS OR ELECTRIC MUST BE EARTHED.
On completion of the installation, these instructions should be left with the Engineer-in-Charge for reference during servicing.
Further to this, The Users Instructions should be handed over to the User, having had a demonstration of the operation and
cleaning of the appliance.
IT IS MOST IMPORTANT THAT THESE INSTRUCTIONS BE CONSULTED BEFORE INSTALLING AND COMMISSIONING
THIS APPLIANCE. FAILURE TO COMPLY WITH THE SPECIFIED PROCEDURES MAY RESULT IN DAMAGE OR THE
NEED FOR A SERVICE CALL.
PREVENTATIVE MAINTENANCE CONTRACT
To obtain maximum performance from this unit regular servicing of the appliance should be undertaken to ensure
correct operation, it is functioning as intended, and safe to use. We recommend servicing in accordance with
SFG20 Maintenance Schedules and as a minimum, after 2,500 hours of use, or annually, whichever comes
and
that a maintenance contract be arranged with an appointed service contact. Visits may then be made at
agreed intervals to carry out adjustments and repairs.
WEEE Directive Registration No. WEE/DC0059TT/PRO
At end of appliance life, dispose of appliance and any replacement parts
in a safe manner, via a licensed waste handler.
Appliances are designed to be dismantled easily and recycling of all
material is encouraged whenever practicable.
Falcon Foodservice Equipment
HEAD OFFICE AND WORKS
Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
Phone: 01786 455200
Fire Precautions Act
Detailed recommendations are contained in Institute of
Gas Engineers published documents:
IGE/ UP/ 1, IGE/ UP/ 2
BS6173 and BS5440
first
T100723 Ref. 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G2962 and is the answer not in the manual?

Questions and answers

Summary of Contents for Falcon G2962

  • Page 1 G2962, G2994 Manual-tilt Bratt Pans INSTALLATION and SERVICING INSTRUCTIONS These appliances must be installed and serviced by a qualified person as stipulated by the Gas Safety (Installation & Use) Regulations. IMPORTANT The installer must ensure that the installation of the appliance is in conformity with these instructions and National Regulations in force at the time of installation.
  • Page 2: Section 1 - Installation

    WIDTH DEPTH HEIGHT WEIGHT WEIGHT MODEL G2962 1.3 VENTILATION G2994 This appliance must be installed in a suitably ventilated room in accordance with the regulations in 1.2 SITING force. The appliance should be installed on a level, fireproof...
  • Page 3 IGE/UP/2. The size of pipework from meter to NATURAL (I H) and PROPANE (I P) GAS appliance must not be less than appliance inlet G2962 NATURAL PROPANE connection Rp1/2• (1/2" BSP female). An isolating MAIN BURNER cock that is easily accessible to user must be located...
  • Page 4: Section 2 - Assembly And Commissioning

    1.10 BURNER ADJUSTMENT Warning The only adjustment necessary on main burner is the THIS APPLIANCE MUST BE EARTHED. correct setting of gas pressures as described in 2.4 CONNECTION TO THE WATER SUPPLY Section 1.9. Not applicable to this appliance. No aeration adjustment is provided. Pilot flame should envelop approximately 6mm to 2.5 PRE-COMMISSIONING CHECK 10mm of thermocouple tip.
  • Page 5: Section 3 - Servicing And Conversion

    3. Brief description of the issue 3.2.1 Main Control Panel Ensure pan is in DOWN position. To contact Falcon for a warranty issue dial (UK only) 01786 455 200 and select Warranty Issues Pull off thermostat control knob. from the menu.
  • Page 6 3.3 BURNERS Remove assembly complete with pilot supply pipe and thermocouple by pulling up and away from base Removal of Main Burners of burner compartment. Tilt pan to fully raised position to allow access to burner compartment. Replace in reverse order, ensuring thermocouple end is clean (do not use thread compound) and do not Remove fixings that retain burners to base of over tighten.
  • Page 7 g) Replace in reverse order. Ensure capillary bulb Undo compression fitting nut on burner gas pipe at and sleeving are in identical position to that of original the rear of solenoid valve. component. Disconnect thermocouple and pilot supply pipe at rear and side of control unit.
  • Page 8 Extinguish burners by turning thermostat control 3.10.2 Pilot goes OUT when burner control knob knob to OFF position. is Released. a) Check pilot flame adjustment as above. Re-light burners by turning thermostat knob to b) Check that thermocouple to multifunctional gas position 5 while observing manometer.
  • Page 9: Gas Solenoid Valve

    3.10.7.2 For Longer Periods (Complete Shut- back panel. To remove switch, proceed as follows – down) a) Turn thermostat knob to OFF (fully a) Raise pan slightly so that end of the screw jack is anticlockwise). at least 50mm away from tilt switch. b) Turn burner control knob to OFF position.
  • Page 10: Section 4 - Spare Parts

    SECTION 4 - SPARE PARTS When ordering spare parts, always quote the appliance type and serial number. This information will be found on the data badge attached to the controls cover behind the controls compartment door. Short Spares List • Multifunctional Gas Control •...
