thomann BOTEX Chainhoist Controller CHC-4 User Manual page 15

Starting up the device
NOTICE!
Damage to the device and connected electric chain hoists due to impulse
operation!
Repeated, momentary presses of the [RUN] button can damage the device and
the connected electric chain hoists.
Always press [RUN] for at several seconds, never several times in a row.
1.
Ensure the following:
There is nobody in the work area of the electric chain hoists.
n
The work area is free of obstacles.
n
You have a clear view of the entire work area and can completely monitor the move‐
n
ment process.
The device must not be used unless all conditions are fulfilled.
2.
Turn all rotary switches to the [0] position.
If the emergency stop button is pressed and locked: Make sure that the reason for
pressing the switch is no longer present and turn it clockwise to the operating position.
3.
Connect the electric chain hoists to the unit, either via the CEE sockets or via the multi-
pin industrial connectors.
4. Make sure the supply voltage is correct and the three phases are connected in the cor‐
rect order.
5.
Connect the device to the power supply.
Starting up
Chainhoist Controller CHC-4, CHC-8
Motor Controller
15
