Sumake LMN-W40H Manual

3"x4" air orbital non-vacuum water resistance sander w/hook pad
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SUMAKE
3"X4" Air Orbital Non-Vacuum
Water Resistance Sander W/ Hook Pad
Specification:
Free Speed
Orbit Diameter
Motor
Sanding Pad
Air Consumption
Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
LMN-W40H
10,000 r/min
3 mm
0.24HP (179W)
3"x4" (76x101 mm)
15 CFM (430 L/min)
6.2" (158 mm)
1/4" (6.35 mm)
1/4" (6.35 mm)
90 psi (6.3 bar)
1.58 lbs (0.72 kg)
Noise and Vibration:
Vibration
EN ISO 28927-3
Sound Pressure Level
Load:
3.94 m/s²
Uncertainty
²
K= 1.5 m/s
Noise
EN ISO 15744
Please always
load: 83.5 dB(A)
Sound power level
environment
load: 94.5 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
K= 3dB
LMN-W40H-S-2002B-XPF
Remark
wear ear
protector at
hearing!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LMN-W40H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sumake LMN-W40H

Summary of Contents for Sumake LMN-W40H

  • Page 1 1/4” (6.35 mm) Air Hose (I.D.) risk of impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! ² K= 1.5 m/s K= 3dB Net Weight 1.58 lbs (0.72 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 LMN-W40H-S-2002B-XPF...
  • Page 2 3"x4"(75x100MM) AIR ORBITAL NON-VACUUM SANDER, W/ HOOK(VINYL) PAD LMC-40H(HM) 3"x4"(75x100MM) AIR ORBITAL CENTRAL-VACUUM SANDER, W/ HOOK(MULTIHOLE HOOK) PAD LMG-40H(HM) 3"x4"(75x100MM) AIR ORBITAL SELF-GENERATED VACUUM SANDER, W/ HOOK(MULTIHOLE HOOK) PAD LMN-W40H 3"x4"(75x100MM) AIR ORBITAL NON-VACUUM WATER RESISTANCE SANDER W/ HOOK PAD LMN(C)(G)-40(LMN-W40H)-P-2002C-XP...
  • Page 3 1" Vac Hose To Double Bag Fitting And Airline Assembly XPG0070 Machined Housing (No Brand) XPA0468 Vacuum Bag XPF0106 3"x4" Side Cover (Black) XPC0109 Vacuum Bag Insert XPA0768 Hex Socket Button Head Machine Screw (M4x12) XPG0118 3"x4" Swivel Exhaust Fitting Assembly [LMN-W40H] LMN(C)(G)-40(LMN-W40H)-P-2002C-XP...

  • Page 4: Ec Declaration Of Conformity

    DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： 3"X4" AIR ORBITAL NON-VACUUM WATER RESISTANCE SANDER W/ HOOK PAD Model/ Serial No.： LMN-W40H to which this declaration applies, complies with these normative documents: Machinery Directive: 2006/42/EC ...
  • Page 5 ITEM NO.: 3"x4"(75x100MM) AIR ORBITAL CENTRAL-VACUUM SANDER W/ HOOK (MULTIHOLE HOOK) PAD LMG-40H(HM) ITEM NO.: 3"x4"(75x100MM) AIR ORBITAL SELF-GENERATED VACUUM SANDER W/ HOOK (MULTIHOLE HOOK) PAD LMN-W40H ITEM NO.: 3"x4"(75x100MM) AIR ORBITAL NON-VACUUM WATER RESISTANCE SANDER W/ HOOK PAD LMN(C)(G)-40(LMN-W40H)-I-2002B-XP...

  • Page 6: Work Stations

    Work Stations The tool is intended to be operated as a hand held tool. It is always recommended that the tool be used when standing on a solid floor. It can be in any position but before any such use, the operator must be in secure position having a firm grip and footing and be aware that the sander can develop a torque reaction.

  • Page 7: Motor Disassembly

    Back-Up Pads SUMAKE on the low profile orbital sander. The molded urethane 3 in. x 4 in. pads are perfectly mated for use pads are constructed from premium, industrial-quality materials Description Screw-On, Non-Vacuum, Vinyl Face Pad Screw-On, Non-Vacuum, Hook Face Pad...

  • Page 8: Housing Disassembly

    However, the filter should be replaced on re-assembly Housing Disassembly: 1. For Non-Vacuum (LMN-40H(V)/ LMN-W40H) and Central Vacuum (LMC-40H(HM)) machines follow steps A - C below (unless otherwise noted). For Self Generated Vacuum (LMG-40H(HM)) machines disregard steps A - F and move onto Step G below.

  • Page 9: Motor Assembly

    taking the male end of the Swivel Exhaust Assembly and placing it into the female end of the Snap-In Exhaust Adapter. Screw the SGV Retainer Assembly into the threaded exhaust port on the Housing with an 8 mm hex key. See the “Parts Page” for torque settings.
  • Page 10 Bearing using the larger end of the T-13 Bearing Press Sleeve (Included in AVA0486 Kit - See “Service Tools and Accessories”) until the front Bearing is seated in the bearing pocket of the Front Endplate. CAUTION: Only press just enough to seat the Bearing into the pocket. Over-pressing can damage the Bearing. 4.

  • Page 11: Troubleshooting

    Troubleshooting: Symptom Possible Cause Solution Check air line pressure at the Inlet of the Sander while the tool is running at free Insufficient air Pressure speed. It must be 6.2 Bar (90 psig/ 620 kPa). See the "Housing Disassembly" section for Blocked Muffler(s) Muffler removal.

  • Page 12: Safety Precautions

    Safety Precautions 1. General safety rules: ⚫ “Read and understand the safety instructions before installing, operating, repairing, maintaining, changing accessories on, or working near the sander or polisher. Failure to do so can result in serious bodily injury.” “Only qualified and trained operators should install, adjust or use the sander or polisher.” ⚫...
  • Page 13 Instructions for setting and testing; ⚫ General instructions for use, including changing inserted tools and limits on size and type of workpiece; ⚫ ⚫ Instructions stating that a tool shall not be operated at a speed exceeding the rated speed www.SUMAKE.com www.AIRCOMPRESSOR.com.tw...
