SUMAKE
Specification:
Free Speed
Sanding Pad
Overall Length
Air Consumption
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
55° Bendable Air Belt Sander
(20x520mm) (Rubber Pully)
ST-BS112G
16,000 r/min
7/8" x 20"
(20mm x 520mm)
14-3/5" (370 mm)
17 CFM (480 L/min)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
2.8 lbs (1.27 kg)
PNEUMATIC TOOLS
Noise and Vibration:
Vibration
EN ISO 28927-3
No Load:
2.8 m/s²
Uncertainty
K= 1.5 m/s
Noise
EN ISO 15744
Sound Pressure Level
load: 95 dB(A)
Sound power level
load: 106 dB(A)
Uncertainty
K= 3dB
²
ST-BS112G-S-2310C-D5F
Remark
Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
hearing!
Advertisement
Related Manuals for Sumake ST-BS112G
Summary of Contents for Sumake ST-BS112G
- Page 1 3/8” (10 mm) dB(A) due to risk of impaired Air Pressure 90 psi (6.3 bar) Uncertainty Uncertainty hearing! K= 1.5 m/s K= 3dB ² Net Weight 2.8 lbs (1.27 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-BS112G-S-2310C-D5F...
- Page 2 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： 55° BENDABLE AIR BELT SANDER (20x520mm) (RUBBER PULLY) Model/ Serial No.： ST-BS112G to which this declaration applies, complies with these normative documents: ...
- Page 3 Avoid storing the tool in a location subject to Method SUMAKE is a manufacturer and exporter of air content separated, as soon as the air leaves the high humidity. If the tool is left as it is used , the tools since established.
- Page 4 ST-BS112G 55° BENDABLE AIR BELT SANDER (20x520mm) (RUBBER PULLY) PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty BS112G-01 Rubber Pully BS110E-35 Rotor Blade BS111G-02 Washer BS110E-36 Cylinder BS111G-03 Bearing BS110E-37 Rear End Plate BS111G-04 Idle Pulley Screw (M6x16)
