SUMAKE
Low Profile Non-Vacuum Air Orbital
Waterproof Sander W/3" Hook Pad
Specification:
Free Speed
Orbit Diameter
Sanding Pad
Motor
Air Consumption
Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
LSN-W30H
12,000 r/min
5.0 mm
3" (76.2 mm)
0.3HP (223W)
15 CFM (430 L/min)
6.0" (152.5 mm)
1/4" (6.35 mm)
1/4" (6.35 mm)
90 psi (6.3 bar)
1.47 lbs (0.66 kg)
Noise and Vibration:
Vibration
EN ISO 28927-3
Sound Pressure Level
Load:
2.61 m/s²
Sound power level
Uncertainty
K= 1.5 m/s
²
Noise
EN ISO 15744
Please always
load: 74.5 dB(A)
protector at
environment
load: 85.5 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
K= 3dB
LSN-W30H-S-1812A-XPF
Remark
wear ear
hearing!
Advertisement
Table of Contents
Related Manuals for Sumake LSN-W30H
Summary of Contents for Sumake LSN-W30H
- Page 1 Air Hose (I.D.) 1/4” (6.35 mm) risk of impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! K= 1.5 m/s ² K= 3dB Net Weight 1.47 lbs (0.66 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 LSN-W30H-S-1812A-XPF...
- Page 2 LOW PROFILE NON-VACUUM AIR ORBITAL SANDER W/ 3" HOOK (VINYI) PAD LSC-30H(V) LOW PROFILE CENTRAL-VACUUM AIR ORBITAL SANDER W/ 3" HOOK (VINYI) PAD LSG-30H(V) LOW PROFILE SELF GENERATED VACUUM AIR ORBITAL SANDER W/ 3" HOOK (VINYI) PAD LSN-W30H LOW PROFILE NON-VACUUM AIR ORBITAL WATERPROOF SANDER W/3" HOOK PAD LSN(C)(G)-30(LSN-W30)-P-2310B-XP...
- Page 3 XPA0043 Ring XPA0778 1" / 28mm Hose Seal [LSG] XPF0057 Throttle Lever For 12,000 rpm, 5mm(3/16") Orbit Sander [SUMAKE] XPA0392 Φ1" Vac Hose To 1"x1-1/2" Adaptor Coupler & Air Line Assembly Opt. XPF0052 Throttle Lever For 12,000 rpm, 2.5mm (3/32 in.) Orbit Sander XPA0412 Φ1"...
-
Page 4: Ec Declaration Of Conformity
DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： LOW PROFILE NON-VACUUM AIR ORBITAL WATERPROOF SANDER W/3" HOOK PAD Model/ Serial No.： LSN-W30H to which this declaration applies, complies with these normative documents: Machinery Directive: 2006/42/EC ... - Page 5 INSTRUCTION MANUAL LSN-W30H, LSN-W30H-2.5 ITEM NO.: LOW PROFILE NON-VACUUM AIR ORBITAL WATERPROOF SANDER W/3" HOOK PAD LSN-W30H-I-2005B-XP...
-
Page 6: Work Stations
Work Stations The tool is intended to be operated as a hand held tool. It is always recommended that the tool be used when standing on a solid floor. It can be in any position but before any such use, the operator must be in a secure position having a firm grip and footing and be aware that the sander can develop a torque reaction. -
Page 7: Motor Disassembly
Back-Up Pads SUMAKE back-up pads are perfectly mated for use on the SUMAKE. Constructed from premium, industrial-quality materials and featuring a riveted fiberglass and steel hub with molded urethane, their durability and precise construction are the ideal complement to the performance of the SUMAKE. See "Product Configuration/Specifications" Table for the correct replacement pad for a particular model. -
Page 8: Housing Assembly
ASSEMBLY INSTRUCTIONS NOTE: All assembly must be done with clean dry parts and all bearings are to be pressed in place by the correct tools and procedures as outlined by the bearing manufacturers. Housing Assembly: Install Throttle Lever into Housing with the Spring Pin. Lightly grease the O-ring and place it on the Speed Control. -
Page 9: Motor Assembly
Motor Assembly: Use the larger end of the T-13 Bearing Press Sleeve to Press the front Bearing (with 2 Shields) onto the shaft of the Shaft Balancer. Slide the Front Endplate with the bearing pocket fac-ing down onto the Motor Shaft. Gently press the Front Endplate onto the front Bearing using the larger end of the T-13 Bearing Press Sleeve until the front Bearing is seated in the bearing pocket of the Front Endplate. -
Page 10: Troubleshooting
Troubleshooting: Symptom Possible Cause Solution Check air line pressure at the Inlet of Insufficient Air Pressure the Sander while the tool is running at free speed. It must be 90 PSI (6.3 Bar). See the "Housing Disassembly" section for Muffler removal. The Muffler can be back flushed with a clean, suitable cleaning solution until all contaminates Clogged Muffler(s) - Page 12 NOTE www.SUMAKE.com www.AIRCOMPRESSOR.com.tw...
