- Page 1 Operating Instructions POLIRET MINI REITEL Feinwerktechnik GmbH Senfdamm 20 | 49152 Bad Essen Phone: +49(0)5472-9432-0 | Fax: +49(0)5472-9432-40 www.reitel.com | info@reitel.com...
- Page 2 Dear Customer! The POLIRET MINI is a compact polishing unit with a powerful motor. It is equipped with a right side mounted spindle. The polishing unit is perfectly suitable for grinding, polishing, cleaning and brushing metal and plastic materials. Excellent results and high efficiency are achieved by the infinitely variable speed from 1.000 - 4.500 rpm.
-
Page 3: Table Of Contents
INDEX TECHNICAL DESCRIPTION ................... 4 B ......................4 ASIC QUIPMENT S ....................4 PECIAL CCESSORIES D ....................4 EVICE OMPONENTS T ......................5 ECHNICAL SAFETY NOTES ......................6 G ....................6 ENERAL AFETY OTES ... -
Page 4: Technical Description
Technical Description Basic Equipment Polishing unit POLIRET MINI with polishing spindle, working lamp and filter bag Special Accessories Order-No.: 24800000 Vario Lifting table Order-No.: 22603000 Workholding fixture incl. drill chuck Order-No.: 22702100 Filter bag with zipper... -
Page 5: Technical Data
Interior view Technical Data Line voltage 230 V/50–60 Hz Motor power 600 W Extraction 115 W Height/width/depth 430/530/400 mm Weight 24 kg Infinitely variable speed 1.000 – 4.500 rpm Extraction 500 m³/h Sound level ≤ 70 dB(A) Housing Stainless steel Made in Germany (Subject to modifications) -
Page 6: Safety Notes
Safety Notes General Safety Notes All equipment undergoes final inspection and testing before leaving our factory. However, if equipment is damaged during shipping or through any other circumstances, it must not be used in service. Please check the device regularly for damages. Damaged parts should be replaced immediately. -
Page 7: Specific Safety Notes
Specific Safety Notes Note: The tool must be securely fixed to the spindle, otherwise there is a risk of injury! If motor speed is too high there is danger of burning! Keep the housing dry and clean. ... -
Page 8: Installation
Installation The electrical equipment is delivered fully installed. The sealed plug can be connected directly to the mains supply 230 V/16 A. For installation please refer to Safety Notes in chapter 2. Installation Leave enough space (at least 20 cm) to accommodate exhaust. Establish the power supply. Tool Assembly 1. -
Page 9: Filter Replacement And Cleaning
Filter Replacement and Cleaning 1. Remove fixing screw (8) on top of the device to remove the cover. 2. Release clamping ring (11) to remove the old filter bag (10). 3. Empty the filter bags, if necessary, wash them: a. a. Water-soluble contaminants can be washed with cold or 40-50°C warm water in a trough or washing machine. -
Page 10: Maintenance
Machine runs unevenly. Check for unbalanced polishing disc or spindle Maintenance Regularly check the device for visible damage to the housing or power cord. Clean regularly dirty tools as well as the tray (9). Replace worn or defective tools reguarly. ... -
Page 11: Warranty
Warranty We, REITEL Feinwerktechnik GmbH, offer a 1 year’s warranty beginning from the proven date of purchase. This warranty covers all defects traceable to materials, design or workmanship. The following warranty regulations are applicable: Within the warranty period Reitel Feinwerktechnik GmbH or an authorized distributor agrees at its sole option, to perform repair or replace this product at no charge covering all defects traceable to materials, design or workmanship. - Page 12 REITEL Feinwerktechnik GmH; The warranty does not cover the cost of removal and replacement of parts and accessories, unless supplied as original equipment by REITEL Feinwerktechnik GmbH All kind of damages occurred not directly at the device as well as consequential damages (e.g.
- Page 13 Should you need to borrow a device while your device is being repaired, please contact Messrs. REITEL or your distributor. These loans are a service for which availability cannot necessarily be guaranteed. After the warranty period, a free may be charged for loan...
-
Page 14: Disposal Regulations
Disposal Regulations According to valid regulations our devices are properly disposed of according to B2B – Regulations for proper disposal. For further information please contact your local dealer. -
Page 15: Spare Parts List
Spare Parts List Best.-Nr. Poliret mini (VA)/(Stainless steel) 54.2 Stck/ME Ref.: Ersatzteilliste / Spare Parts List Qty. Unit E6269000 Ablageschale Kunststoff schwarz - ab Geräteno. 635 Stck/piece 22702100 Filterbeutel mit Reissverschluss / Filter bag with zipper Stck/piece Schutzscheibe, Acryl, ab Gerätenummer 635 /... -
Page 16: Eu Directive
EU DIRECTIVE... - Page 17 We manufacture in compliance with Quality Management ISO 13485:2016 incorporating established process standards. REITEL Feinwerktechnik GmbH Senfdamm 20 | 49152 Bad Essen Phone: +49(0)5472-9432-0 | Fax: +49(0)5472-9432-40 www.reitel.com | info@reitel.com...
