Method 1 (using 2 keys)

Wait until the LED turns ON solid red.

Note: To skip the transponder programming and use convenience features only, press the

programming button 5 times. Wait until the LED turns ON solid orange, then proceed with

step 2.

Insert the first key and turn it to the ON position, then turn it back OFF. The LED starts flashing

green.

If the transponder programming was skipped, the LED turns ON solid orange for 3 seconds

then shuts OFF when programming is done.

Insert the second key and turn it to the ON position, then remove it. The LED starts flashing

orange.

Press and hold the module programming button, and the ignition will turn ON.

Once the configuration is completed, the LED turns ON solid green for 3 seconds, then shuts

OFF.

Release the programming button.

You have successfully completed the module programming sequence.

403.FORD7 2.13 2012 Ford Fiesta
