Product Description; Short Description; Name Plate - Danfoss BOCK HG4 Operating Manual

2| Product description

2.1 Short description

• Semi-hermetic four-cylinder reciprocating compressor with suction-gas cooled drive motor.
• Flange-mounted drive motor on the compressor case.
• Preferred application range: normal refrigerating and air-conditioning.
Terminal box
Transport eyelet
Valve plate
Discharge
D
shut-off valve
GB
Oil pump
F
E
I
Ru
Dimension and connection values can be found in Chapter 9
6 | AQ452034894212en-000201
y
7 m an
st r. G er
nz n,
, Be se
bH au
G m ic ke nh
ck
Bo 6 Fr
63
72
Fig. 1
© Danfoss | Climate Solutions | 2023.06
Suction shut-
off valve
Motor section
Cylinder cover

Name plate

Drive section
Oil sight glass
