Summary of Contents for ROBINHOOD HEE604TFG
- Page 1 Installation and Operating Instructions Issue: 3 Description: ROBINHOOD 60CM CERAMIC COOKTOP Model Number: HEE604TFG...
-
Page 2: Table Of Contents
Due to continual product development, Robinhood reserves the right to alter specifications or appearances without notice. Important Safety Instructions..........................1 Product Description .............................. -
Page 3: Important Safety Instructions
Important Safety Instructions IMPORTANT: Read the assembly instruction section and safety precautions of this booklet carefully before removing the contents of this carton. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. -
Page 4: Product Description
Product Description Model HEE604TFG Voltage 220-240VAC ~50Hz Rated Power 6400W Element Zones 1. Cooking zone rear left button 8. Safety lock button 2. Cooking zone front left button 9. Plus button 3. Cooking zone front right button 10. Rear left cooking zone indicator 4. -
Page 5: Installation Instructions
Installation Instructions Kitchen furniture and cabinetry that is in direct contact with the appliance must be heat resistant to a • minimum temperature of 100°C. The appliance can be installed on a bench with a thickness of between 30 and 40 mm. •... - Page 6 Installation Instructions Installing the Cooktop Note: Before proceeding with installation read the work instructions carefully. 1. Place a towel or cloth on the work surface. Place the cooktop face down on the protected surface. 2. Apply the strip seal, supplied with the hob, which is for sealing it onto the work surface.
- Page 7 Installation Instructions Electrical Connection Supply connection: 30A (double pole switched fused outlet with minimum 3mm contact gap) Before connecting the appliance, ensure that the supply voltage marked on the data label corresponds with your mains supply voltage. WARNING: This appliance must be earthed. Ensure that the power supply cable does not exceed a temperature of 50°C.
-
Page 8: Operating Instructions
Operating Instructions First Time Usage IMPORTANT: You should clean the ceramic hob surface (see “Maintenance and cleaning” section). Turn each element on, one at a time, and leave them to run at full heat for five minutes. This will help to eliminate any new smell that exists and evaporate any humidity that has formed on the heating elements during transit. -
Page 9: Maintenance And Cleaning
Operating Instructions Timer The timer has a range of 1-99 minutes. To use the timer, follow the below steps: 1. Press the timer button. 2. Use the ‘+’ and ‘-‘ buttons to adjust the timer to the desired time limit (these can be held down to adjust the timer quicker). -
Page 10: Warranty Certificate (New Zealand)
The following conditions apply in respect of the warranty given in this certificate: Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: Rangehood, Ovens, Cooktops, Dishwashers, Refrigeration - 24 months from date of original purchase for domestic •... -
Page 11: Warranty Certificate (Australia)
The product was used outdoors. • All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
