Summary of Contents for ROBINHOOD HEF604TCOM
- Page 1 Installation and Operating Instructions Issue: 1 Description: ROBINHOOD 60CM CERAMIC COOKTOP TOUCH CONTROL Model Number: HEF604TCOM Model Pictured: HEF604TCOM *Actual product may vary from model picture...
-
Page 2: Table Of Contents
Due to continual product development, Robinhood reserves the right to alter specifications or appearances without notice. Important Safety Instructions ..........................1 Product Information .............................3... -
Page 3: Important Safety Instructions
Important Safety Instructions IMPORTANT: Read the assembly instruction section and safety precautions of this booklet carefully before removing the contents of this carton. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. - Page 4 Important Safety Instructions 17. The appliance must be installed and put into operation by an authorised technician under the conditions provided by the manufacturer in this manual. The manufacturer cannot be held responsible for any damage that might occur due to faulty installation. 18.
-
Page 5: Product Information
Product Information General Information Before installing and operating the rangehood, carefully read the following important information regarding installation safety and maintenance. Keep this information booklet accessible for further consultations. The appliance has been designed to exhaust cooking fumes externally. Before installation, please ensure that the following have been supplied and that the tools listed below are readily available. -
Page 6: Installation
Installation Cut out the work surface according to the sizes shown in the image below. Ensure that there is a minimum of 50mm of space around the cutout. The thickness of the bench should be at least 30mm. Please select heat-resistant and insulated bench materials (Wood and similar fibrous or hygroscopic materials should not be used as the bench material unless impregnated) to avoid the electrical shock and larger deformation caused by heat radiation from the hotplate. - Page 7 Installation In order to avoid accidentally touching the hot underside of the cooktop, or getting an unexpected electric shock, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 50mm from the bottom of the cooktop. There are ventilation holes around outside of the cooktop.
- Page 8 Installation LOCAL AUTHORITY REQUIREMENTS Installation is only permitted by a licensed electrician and carried out according to instructions provided by the manufacturer. Incorrect installation might cause harm and damage, for which the manufacturer accepts no responsibility. Electrical Installation Before carrying out the connection to the power supply, the voltage rating of the appliance (stamped on the appliance identification plate) must be checked for correspondence to the available mains supply voltage, and the mains electric wiring should be capable of handling the oven’s power rating (also indicated on the identification plate).
-
Page 9: Operating Instructions
Operating Instructions Touch Controls • The controls respond to touch, so you don’t need to apply any pressure. • Use the pad of your finger, not the tip. • You will hear a beep each time a touch is registered. •... - Page 10 Operating Instructions Using the Cooktop When the power is connected you will hear a beep and all the lights will come on for one second and then go out. This indicates that the cooktop has entered standby mode. Turn the cooktop on by touching the On / Off button.
- Page 11 Operating Instructions Using the Timer The timer can be used in two different ways: • You can use it as an alarm. In this case it will not turn any cooking zones off. • You can use it to automatically turn off a cooking zone after the timer has finished. The timer can be set to a maximum of 99 minutes.
- Page 12 Operating Instructions Setting the Timer to turn one or more Cooking Zones Off Touch the “+” or “-“ button of the cooking zone you wish to set the timer for. Set the timer as described on the previous page. A red dot next to the power level for the corresponding cooking zone will illuminate to indicate that the timer has been set for it.
-
Page 13: Maintenance And Cleaning
Maintenance and Cleaning Cleaning Problem Resolution Important • When the power to the cooktop is switched off, there will be no ‘hot surface’ 1. Switch the power to the cooktop off. indication but the cooking zone may still 2. Apply a cooktop cleaner while the glass be hot! Take extreme care. -
Page 14: Troubleshoot
Troubleshoot Troubleshooting Problem Possible causes What to do Make sure the ceramic hob is connected to the power supply and that it is switched on. The cooktop cannot be No power. Check whether there is a power outage in your turned on. -
Page 15: Warranty Certificate (New Zealand)
The following conditions apply in respect of the warranty given in this certificate: Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: •... -
Page 16: Warranty Certificate (Australia)
• The product was used outdoors. All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
