- Page 1 Issue 3 Description: Robinhood Ceramic Touch Control Cooktop 60cm Model Numbers: HEA604TFG...
-
Page 2: Warning And Safety Information
Warning and safety information This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. - Page 3 Installation - continued Built in ceramic cooktop cutout dimensions. HEA604TFG A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) G (mm) Installing the foam gasket Before inserting the appliance into the opening in the kitchen benchtop, the supplied foam gasket must be attached to the lower side of the glass ceramic (glass) cooktop between the benchtop and cooktop.
- Page 4 Installation - continued Installation procedure. Worktop must be placed absolutely horizontal. • Suitably protect the edges of the cut aperture. • Connect the cooktop to the mains power supply (see instructions for the connection of the cooktop to the mains power supply).
- Page 5 Installation - continued Technical information Type HEA604TFG Width 580mm Rated voltage 220-240 V~ or 380-415 V 2N~, 50/60 Hz Type of switch Electronic sensors Cooking zones ( Ø, mm/W ) Forward left 140, 1,2 Rear left 180, 1.8 Rear right 180, 1.8...
- Page 6 Installation - continued Important warnings regarding the glass ceramic cooktop • Cooking zone reaches the selected power level or temperature very quickly; however, the area surrounding the cooking zones remains relatively cool. • The cooktop is resistant to temperature changes. •...
- Page 7 Installation - continued Energy saving tips When buying cookware be careful in selecting size: pot diameter usually refers to the top edge of the dish, which is often larger than the dish bottom. Use such dish size to accommodate the quantity of food to be prepared.
- Page 8 Instructions for use and maintenance Ceramic Glass Cooktop Hi-light hotplate front left Hi-light hotplate rear left Hi-light hotplate rear right Hi-light hotplate front right Cooktop control panel Cooktop control elements ON/OFF sensor ON/OFF indicator LED Slide control sensor . Slide control indicator LED’s Safety lock on/off and child lock sensor .
- Page 9 Instructions for use and maintenance Turning hotplates on After turning the cooktop on using the ON/OFF sensor (A), within the next 20 seconds start one of the hotplates. Touching the desired hotplate sensor (E), its relevant power indicator indicates »0« and decimal dot (E ) changes from flashing fixed.
- Page 10 Instructions for use and maintenance Remaining heat indicator When an active hotplate is switched off, or when the entire cooktop is switched off, the indicator (E) displays »H«, as a signal that a particular »hotplate is still hot«. Display time is calculated in relation to the used heating power and the period the hotplate was active prior switching off. Even when warning signal “H”...
- Page 11 Instructions for use and maintenance Power setting Maximum power cooking time (min.) Safety switch off Power setting Hours lapse prior safety switch off Maximum continuous operation of a particular hotplate is limited, and the duration is displayed in the above chart. When the hotplate is switched off by the safety mechanism, the indicator displays symbols “0”, or “H”...
- Page 12 Instructions for use and maintenance Checking remaining cooking time • Last set timer is always displayed . • Select cooking zone. The residual time of selected cooking zone will be displayed on timer’ Turning time off When preset time elapses, a beep signals the end, and the hotplate is switched off. Switch off the alarm by pressing the sensor of switch-off timer (F),or it switches off automatically after 2 minutes.
-
Page 13: Safety Functions And Error Display
Safety functions and error display Safety functions and error display ERROR CODE ERROR DESCRIPTION INSTRUCTION MANUAL ER03 Permanent use of keys; Control unit cuts off contact the AUTHORIZED SERVICE CENTRE after 10 sec FOR TECHNICAL ASSISTANCE - SPECIFYING THE ERROR CODE ER20 Flash-failure. -
Page 14: Cleaning And Maintenance
Cleaning & maintenance Cleaning and maintenance of ceramic glass cooktop Ceramic glass cooktop should be cleaned only when completely cooled down, preferably after each use, otherwise even the slightest stains remaining after cooking may burn into the cooktop surface with each following use. For regular maintenance of ceramic-glass cooktop use special cleansing agents, produced in such way to create protective film upon the surface. - Page 15 Important information The appliance may be built-in and connected to the power supply only by a qualified technician. Particular areas of the cooktop surface (adjacent to the hotplates) are hot during operation. Hot oil ignites readily, so be sure have the preparation of such food (fries) under constant control. Hotplates may not be left in operation empty, without any dishes on top.
- Page 16 The product was used outdoors. 2. All Robinhood rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. 3. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
- Page 17 The product was not used, cleaned or cared for in accordance with our instructions. The product was used outdoors. All Robinhood rangehoods are suitable for indoor use only, and not suitable over BBQs or charcoal cookers designed for outdoor use.
