Summary of Contents for ROBINHOOD HEF302TCOM
- Page 1 Installation and Operating Instructions Issue: 1 Description: ROBINHOOD 30CM CERAMIC COOKTOP BLACK Model Number: HEF302TCOM...
-
Page 2: Table Of Contents
Due to continual product development, Robinhood reserves the right to alter specifications or appearances without notice. Important Safety Instructions..........................1 Product Description .............................. -
Page 3: Important Safety Instructions
Important Safety Instructions IMPORTANT: Read the assembly instruction section and safety precautions of this booklet carefully before removing the contents of this carton. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. -
Page 4: Product Description
Product Description Model HEF302TCOM Voltage 220-240VAC ~50Hz Rated Power 2900W Element Zones M1= Cooking zone 1 selection 1- Cooking zone indicating digital tube: Display the power M2= Cooking zone 2 selection level , high temperature warning symbol etc. M3= Plus button: For adding time... -
Page 5: Installation Instructions
Installation Instructions Kitchen furniture and cabinetry that is in direct contact with the appliance must be heat resistant to a • minimum temperature of 100°C. The appliance can be installed on a work surface with a thickness of between 30 and 40 mm and near to •... - Page 6 Installation Instructions Installing the Cooktop Note: Before proceeding with installation read the work instructions carefully. 1. Place a towel or cloth on the work surface. Place the cooktop face down on the protected surface. 2. Apply the strip seal, supplied with the hob, which is for sealing it onto the work surface.
- Page 7 Installation Instructions Electrical Connection Supply connection: 30A (double pole switched fused outlet with minimum 3mm contact gap) Before connecting the appliance, ensure that the supply voltage marked on the data label corresponds with your mains supply voltage. WARNING: This appliance must be earthed. Ensure that the power supply cable does not exceed a temperature of 50°C.
-
Page 8: Operating Instructions
Operating Instructions First Time Usage IMPORTANT: You should clean the ceramic hob surface (see “Maintenance and cleaning” section). Turn each element on, one at a time, and leave them to run at full heat for five minutes. This will help to eliminate any new smell that exists and evaporate any humidity that has formed on the heating elements during transit. - Page 9 Operating Instructions MULTIPLE RING HEATING Open the multiple ring heating: The outer ring can only be started when the inner ring is opened. 1- Press the burner select key for heating, the corresponding burner indicator digital tube point “ ” flashing display.
- Page 10 Operating Instructions When setting the automatic heating function, the corresponding cooking zone will be heated in level 9 for a period of time (heating time depends on the subsequent reduction to several levels, the heating time of each level is as follows), then continue working in the final adjusted heating level.
- Page 11 Operating Instructions After the timer countdown is 0, the buzzer will continue to sound for 2 minutes, and you can press any • button to turn off the beep. Note: 1- If the timing of a certain cooking zone has been set, to change the time, press the time button again to select the corresponding cooking zone, and then enter the new time by plus and minus buttons.
- Page 12 Operating Instructions DEFAULT TIMING All of the cooking zones have a default timing function. The cooking zones will automatically turn off after this time has elapsed. See the table below to see the times for the different power levels. Power Level Default timing 1.5h HIGH TEMPERATURE WARNING...
-
Page 13: Troubleshooting
Troubleshooting PCB board fault codes and solutions When a PCB board failure occurs, the timer digital tubes on the display panel always display the fault code, and all the burners that are being heated stop heating, and automatically return to the shutdown state after 1 minute. For the burners that have been worked, the corresponding digital tube continues to display the high temperature warning sign "... -
Page 14: Maintenance And Cleaning
Maintenance and Cleaning Warning: Ensure that the cooktop is cool before cleaning or performing maintenance. Disconnect the cooktop from the power supply before performing any maintenance. Do not use sharp scrapers or abrasive cleaning agents on the cooktop as these can damage it. •... -
Page 15: Warranty Certificate (New Zealand)
The following conditions apply in respect of the warranty given in this certificate: Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: •... -
Page 16: Warranty Certificate (Australia)
The product was used outdoors. • All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
