- Page 1 Issue 12 Description: Robinhood Gas Cooktop 60cm and 90cm Model Numbers: HGA604FKSS, HGAA604FKSS, HGA905FKSS TO BE INSTALLED BY AN AUTHORISED PERSON THESE INSTRUCTIONS CONTAIN IMPORTANT INFORMATION ABOUT INSTALLATION AND USE...
-
Page 2: Warning And Safety Information
Warning and Safety Information This appliance shall be installed only by authorised persons and in accordance with local and national building instructions, local gas fitting regulations, municipal building codes, electrical wiring regulations and AS 5601-2010 Gas Installations and any other statutory regulations. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 3 Operating Instructions Igniting the Burners In these models the knob controls both ignition and the safety device. Proceed as follows to ignite the burners: Depress the chosen knob and turn to the large flame. Keep the knob depressed for 3 to 4 seconds to allow the spark to ignite the burner and to heat the safety device. Release the knob after about 3 to 4 seconds and adjust the flame to the desired setting by rotating the knob anti-clockwise.
- Page 4 Operating Instructions...
-
Page 5: Cleaning And Maintenance
Operating Instructions CLEANING AND MAINTENANCE General Cleaning and maintenance should be carried out regularly while the appliance is cold especially when cleaning the enamelled & Stainless steel parts. Avoid leaving alkaline or acid substances on the surfaces (lemon juice, vinegar etc). Avoid using acid or chlorine based cleaning products. - Page 6 Operating Instructions Gas Taps Periodic lubrication of the gas taps must be carried out by authorised personnel only. In the event of operating faults with the gas taps call an authorised service agent. General Advice • When the appliance is not being used it is advisable to keep the gas tap closed. •...
-
Page 7: Installation
Installation Cutout Dimensions 470mm 552mm 827mm 470mm 50mm... - Page 8 Installation Foreword These cooktops are designed to be embedded into kitchen fixtures measuring 600mm in depth. In order to install the cooktop into the kitchen fixture, a hole with the dimensions shown on the cutting board has to be made, keeping in consideration the following: •...
-
Page 9: Gas Section
Installation Ventilation • Ventilation must be in accordance with AS5601-2010 Gas Installations. • The appliance should have adequate ventilation for complete combustion of gas, proper fluing and to maintain temperature of immediate surroundings within safe limits. Discharging Products of Combustion •... - Page 10 Installation Orientation of the Elbow This appliance is supplied with a Gas Inlet elbow connection located below the maintop, at the rear. The actual location by measurement is 110mm from the right hand side of the 4 burner hob, and 50mm from the left hand side of the 5 burner hob. The connection to the gas supply must be effected only from this side or in vertical position by turning the elbow downwards.
-
Page 11: Electrical Section
Installation Regulating the Burner Minimum Setting When switching from one type of gas to another, the minimum flow rate must be correct so that the flame will not go when changing from maximum to minimum flame. To regulate the flame follow the instructions below: •... - Page 12 Installation - continued For connections to the mains power supply never use adapters, reductions or multiple power points as these may overheat and catch fire. In the event that installation should require modifications to the mains supply wiring system or if the power plug is not suitable for the type of power point available, it is recommended that a qualified technician be called to carry out substitution.
-
Page 13: Pre-Installation
The following conditions apply in respect of the warranty given in this certificate: 1. Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: Rangehood, Ovens, Cooktops, Dishwashers - 24 months from date of original purchase for domestic use. - Page 14 The product was used outdoors. 2. All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. 3. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
